78HT2 Series
Manufacturer: Texas Instruments
Beta
⌘K
DC DC CONVERTER 3.3V
| Part | Current - Output (Max) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Type | Voltage - Input (Max) [Max] | Number of Outputs | Voltage - Output 1 | Package / Case | Features | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Mounting Type | Voltage - Input (Min) [Min] | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 2 A | 85 °C | -40 °C | Non-Isolated PoL Module | 15 V | 1 | 3.3 V | 3-SIP Module | OTP SCP | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | Through Hole Right Angle | 7 V | ITE (Commercial) |
 Texas Instruments | 2 A | 85 °C | -40 °C | Non-Isolated PoL Module | 28 V | 1 | 5 V | 3-SIP Module | OTP SCP | 7.9 mm | 22.9 mm | 23.9 mm | 0.31 " | 0.94 in | 0.9 " | Through Hole | 7 V | ITE (Commercial) |
Texas Instruments | 2 A | 85 °C | -40 °C | Non-Isolated PoL Module | 28 V | 1 | 5 V | 3-SIP Module | OTP SCP | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | Through Hole Right Angle | 7 V | ITE (Commercial) |
Texas Instruments | 2 A | 85 °C | -40 °C | Non-Isolated PoL Module | 28 V | 1 | 5.25 V | 3-SIP Module | OTP SCP | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | Through Hole Right Angle | 7.25 V | ITE (Commercial) |
Texas Instruments | 2 A | 85 °C | -40 °C | Non-Isolated PoL Module | 15 V | 1 | 3.3 V | 3-SIP Module | OTP SCP | 7.9 mm | 22.9 mm | 23.9 mm | 0.31 " | 0.94 in | 0.9 " | Through Hole | 7 V | ITE (Commercial) |
