LSXA4 Series

Catalog

SWITCH SNAP ACTION SPDT 10A 120V

Part	Pretravel	Actuator Type	Operating Temperature [Max]	Operating Temperature [Min]	Overtravel	Operating Force	Voltage Rating - DC	Features	Current Rating (Amps)	Voltage Rating - AC	Differential Travel	Mounting Type	Switch Function	Termination Style	Circuit
Honeywell Sensing and Productivity Solutions LSXA4K	15 °	Side Rotary - No Lever	121 °C	-12 °C	60 °	46 gfm	115 V	Explosion Proof	10 A 800 mA	120 V	5 °	Chassis Mount	On-Mom	Screw Terminal	SPDT (DB/DM)
Honeywell Sensing and Productivity Solutions LSXA4L-2C	15 °	Side Rotary Adjustable Roller	121 °C	-12 °C	60 °	46 gfm	115 V	Front Mounted Nylon Roller	10 A 800 mA	120 V	7 °	Chassis Mount	On-Mom	Screw Terminal	DPDT (DB/DM)
Honeywell Sensing and Productivity Solutions LSXA4L-1A	15 °	Roller Side Rotary	121 °C	-12 °C	60 °	46 gfm	115 V		10 A 800 mA	120 V	7 °	Chassis Mount	On-Mom	Screw Terminal	DPDT (DB/DM)
Honeywell Sensing and Productivity Solutions LSXA4K-2C	15 °	Side Rotary Adjustable Roller	121 °C	-12 °C	60 °	46 gfm	115 V	Front Mounted Nylon Roller	10 A 800 mA	120 V	5 °	Chassis Mount	On-Mom	Screw Terminal	SPDT (DB/DM)
Honeywell Sensing and Productivity Solutions LSXA4L3-2C	15 °	Side Rotary Adjustable Roller	121 °C	-12 °C	60 °	46 gfm	115 V	Front Mounted Nylon Roller	10 A 800 mA	120 V	7 °	Chassis Mount	On-Mom	Screw Terminal	DPDT (DB/DM)
Honeywell Sensing and Productivity Solutions LSXA4L-4M	15 °	Side Rotary Adjustable Rod	121 °C	-12 °C	60 °	46 gfm	115 V	Explosion Proof	10 A 800 mA	120 V	7 °	Chassis Mount	On-Mom	Screw Terminal	DPDT (DB/DM)
