895-030 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 30POS 0.100
...
| Part | Material - Insulation | Termination Rows [custom] | Termination | Contact Material | Contact Finish | Number of Positions | Read Out | Color | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Contact Type | Number of Positions/Bay/Row | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Gender | Flange Feature | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Solder | Copper Alloy | Gold | 30 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Cantilever | 15 | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | Flush Mount M3 Threaded Insert Top Opening | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Solder | Copper Alloy | Gold | 30 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Cantilever | 15 | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | 2 | 3.25 mm | 0.128 " | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Copper Alloy | Gold | 30 | Single | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Cantilever | 30 | Non Specified - Single Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | 3.25 mm | 0.128 " | 1 | 1 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Copper Alloy | Gold | 30 | Single | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Cantilever | 30 | Non Specified - Single Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | 4-40 Threaded Insert Top Mount Opening | 1 | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Wire Wrap | Copper Alloy | Gold | 30 | Single | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Cantilever | 30 | Non Specified - Single Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | 1 | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Solder | Copper Alloy | Gold | 30 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Cantilever | 15 | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | 2 | 3.96 mm | 0.156 " | Card Extender | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Copper Alloy | Gold | 30 | Single | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Cantilever | 30 | Non Specified - Single Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | 3.96 mm | 0.156 " | 1 | 1 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Solder | Copper Alloy | Gold | 30 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Cantilever | 15 | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | Flush Mount Top Opening Unthreaded | 2 | 3.96 mm | 0.156 " | Card Extender | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Wire Wrap | Copper Alloy | Gold | 30 | Single | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Cantilever | 30 | Non Specified - Single Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | M3 Threaded Insert Top Mount Opening | 1 | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Wire Wrap | Copper Alloy | Gold | 30 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Cantilever | 15 | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | M3 Threaded Insert Top Mount Opening | 2 |
