R4HBLKBL Series
Manufacturer: E-Switch
Beta
⌘K
SWITCH ROCKER SPST-NC 20A 125V
| Part | Mechanical Life | Electrical Life | Approval Agency | Current Rating (Amps) | Actuator Marking | Switch Function | Operating Temperature [Max] | Operating Temperature [Min] | Color - Actuator/Cap | Panel Cutout Dimensions [x] | Panel Cutout Dimensions [y] | Voltage Rating - AC | Mounting Type | Actuator Type | Circuit | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 E-Switch | 30000 Steps | 6000 Cycles | UL | 20 A | No Marking | On-Mom | 55 °C | -20 ░C | Black | 30.1 mm | 11.1 mm | 125 V | Panel Mount Snap-In | Concave (Curved) | SPST-NC | Quick Connect - 0.250" (6.3mm) |
