895-094 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 94POS 0.100
| Part | Read Out | Gender | Termination Rows [custom] | Number of Rows [custom] | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Material - Insulation | Number of Positions | Contact Material | Color | Card Type | Contact Finish | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Termination | Mounting Type | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Dual | Female | 2 | 2 | 0.1 " | 2.54 mm | 125 °C | -40 C | Polyphenylene Sulfide (PPS) | 94 | Copper Alloy | Black | Non Specified - Dual Edge | Gold | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Through Hole | 47 | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Dual | Female | 2 | 2 | 0.1 " | 2.54 mm | 125 °C | -40 C | Polyphenylene Sulfide (PPS) | 94 | Copper Alloy | Black | Non Specified - Dual Edge | Gold | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Through Hole | 47 | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Dual | Female | 2 | 2 | 0.1 " | 2.54 mm | 125 °C | -40 C | Polyphenylene Sulfide (PPS) | 94 | Copper Alloy | Black | Non Specified - Dual Edge | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Through Hole | 47 | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | Dual | Female | 2 | 2 | 0.1 " | 2.54 mm | 125 °C | -40 C | Polyphenylene Sulfide (PPS) | 94 | Copper Alloy | Black | Non Specified - Dual Edge | Gold | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Through Hole | 47 | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Dual | Female | 2 | 2 | 0.1 " | 2.54 mm | 125 °C | -40 C | Polyphenylene Sulfide (PPS) | 94 | Copper Alloy | Black | Non Specified - Dual Edge | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Board Edge Straddle Mount | 47 | 0.25 Ám | 10 Áin | Card Extender | ||
 EDAC Inc. | Dual | Female | 2 | 2 | 0.1 " | 2.54 mm | 125 °C | -40 C | Polyphenylene Sulfide (PPS) | 94 | Copper Alloy | Black | Non Specified - Dual Edge | Gold | 0.128 " | 3.25 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Through Hole | 47 | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Dual | Female | 2 | 2 | 0.1 " | 2.54 mm | 125 °C | -40 C | Polyphenylene Sulfide (PPS) | 94 | Copper Alloy | Black | Non Specified - Dual Edge | Gold | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Right Angle Through Hole | 47 | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Dual | Female | 2 | 2 | 0.1 " | 2.54 mm | 125 °C | -40 C | Polyphenylene Sulfide (PPS) | 94 | Copper Alloy | Black | Non Specified - Dual Edge | Gold | 0.156 " | 3.96 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Through Hole | 47 | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Dual | Female | 2 | 2 | 0.1 " | 2.54 mm | 125 °C | -40 C | Polyphenylene Sulfide (PPS) | 94 | Copper Alloy | Black | Non Specified - Dual Edge | Gold | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Right Angle Through Hole | 47 | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Dual | Female | 2 | 2 | 0.1 " | 2.54 mm | 125 °C | -40 C | Polyphenylene Sulfide (PPS) | 94 | Copper Alloy | Black | Non Specified - Dual Edge | Gold | 0.156 " | 3.96 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Right Angle Through Hole | 47 | 0.25 Ám | 10 Áin |
