337-012 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 12POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Number of Rows [custom] | Termination | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Color | Number of Positions | Contact Finish | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Contact Material | Card Type | Number of Positions/Bay/Row | Mounting Type | Read Out | Features | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 2 | Solder | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Female | Green | 12 | Gold | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Cantilever | Copper Alloy | Non Specified - Dual Edge | 12 | Through Hole | Dual | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 2 | Solder Eyelet(s) | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Female | Green | 12 | Gold | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Cantilever | Copper Alloy | Non Specified - Dual Edge | 12 | Board Edge Straddle Mount | Dual | Card Extender | ||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Wire Wrap | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Female | Green | 12 | Gold | Flush Mount M3 Threaded Insert Top Opening | Cantilever | Copper Alloy | Non Specified - Single Edge | 12 | Through Hole | Single | 1 | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 2 | Wire Wrap | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Female | Green | 12 | Gold | 4-40 Threaded Insert Top Mount Opening | Cantilever | Copper Alloy | Non Specified - Dual Edge | 12 | Through Hole | Dual | |||||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Solder | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Female | Green | 12 | Gold | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Cantilever | Copper Alloy | Non Specified - Single Edge | 12 | Through Hole | Single | 1 | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 2 | Solder | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Female | Green | 12 | Gold | Cantilever | Copper Alloy | Non Specified - Dual Edge | 6 | Through Hole | Dual | ||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 2 | Wire Wrap | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Female | Green | 12 | Gold | 0.128 " | 3.25 mm | Cantilever | Copper Alloy | Non Specified - Dual Edge | 12 | Right Angle Through Hole | Dual | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 2 | Solder | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Female | Green | 12 | Gold | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Cantilever | Copper Alloy | Non Specified - Dual Edge | 6 | Board Edge Straddle Mount | Dual | Card Extender | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 2 | Wire Wrap | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Female | Green | 12 | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | Copper Alloy | Non Specified - Dual Edge | 6 | Through Hole | Dual | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 2 | Solder | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Female | Green | 12 | Gold | M3 Threaded Insert Top Mount Opening | Cantilever | Copper Alloy | Non Specified - Dual Edge | 12 | Board Edge Straddle Mount | Dual | Card Extender |
