M2T23TX Series

Catalog

SWITCH ROCKER DPDT 6A 125V

Part	Mechanical Life	Electrical Life	Mounting Type	Circuit	Actuator Marking	Actuator Type	Current Rating (Amps)	Features	Operating Temperature [Max]	Operating Temperature [Min]	Switch Function	Voltage Rating - DC	Voltage Rating - AC	Termination Style	Color - Actuator/Cap	Approval Agency
NKK Switches M2T23TXW13-FC	50000 Cycles	25000 Steps	Through Hole	DPDT	No Marking	Concave	3 A 6 A	Process Sealed	85 °C	-30 ░C	On-Off-On	30 V	125 V	PC Pin	Red	CSA UL
NKK Switches M2T23TXW30	50000 Cycles	25000 Steps	Right Angle Through Hole	DPDT	Varies by Cap	Actuator Arm Cap Required	3 A 6 A	Process Sealed	85 °C	-30 ░C	On-Off-On	30 V	125 V	PC Pin		CSA UL
NKK Switches M2T23TXG13	50000 Cycles	50000 Cycles	Through Hole	DPDT	Varies by Cap	Actuator Arm Cap Required	0.4 VA	Process Sealed	85 °C	-30 ░C	On-Off-On	28 V	28 V	PC Pin		CSA UL
NKK Switches M2T23TXG13-GF	50000 Cycles	50000 Cycles	Through Hole	DPDT	No Marking	Paddle	0.4 VA	Process Sealed	85 °C	-30 ░C	On-Off-On	28 V	28 V	PC Pin	Green	CSA UL
NKK Switches M2T23TXW13	50000 Cycles	25000 Steps	Through Hole	DPDT	Varies by Cap	Actuator Arm Cap Required	3 A 6 A	Process Sealed	85 °C	-30 ░C	On-Off-On	30 V	125 V	PC Pin		CSA UL
NKK Switches M2T23TXW30-FA	50000 Cycles	25000 Steps	Right Angle Through Hole	DPDT	No Marking	Concave	3 A 6 A	Process Sealed	85 °C	-30 ░C	On-Off-On	30 V	125 V	PC Pin	Black	CSA UL
NKK Switches M2T23TXG13-EG	50000 Cycles	50000 Cycles	Through Hole	DPDT	No Marking	Paddle	0.4 VA	Process Sealed	85 °C	-30 ░C	On-Off-On	28 V	28 V	PC Pin	Blue	CSA UL
NKK Switches M2T23TXG13-DA	50000 Cycles	50000 Cycles	Through Hole	DPDT	No Marking	Concave	0.4 VA	Process Sealed	85 °C	-30 ░C	On-Off-On	28 V	28 V	PC Pin	Black	CSA UL
