628-17W Series
Manufacturer: EDAC Inc.
Beta
⌘K
COMBINATION LAYOUT D SUB CONNECTOR, 628C SERIES, DC-17W5, RECEPTACLE, 17 CONTACTS
| Part | Color | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Voltage Rating | Contact Material | Connector Type | Number of Positions | Material Flammability Rating | Termination | Contact Type | Current Rating (Amps) | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Number of Rows [custom] | Connector Style | Features | Contact Finish | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Shell Size, Connector Layout | Contact Finish Thickness | Current Rating (Amps) | Number of Positions [custom] | Number of Positions [custom] | Shell Material, Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Copper Alloy | Receptacle Female Sockets | 17 | UL94 V-0 | Solder | Signal and Power | 5 A 40 A | 4 | DC C - 17W5 | 2 | Combo D-Sub | Board Lock Shielded | Gold | Through Hole | 30 Áin | 0.76 Ám | Board Side (M3) | ||||||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Copper Alloy | Receptacle Female Sockets | 17 | UL94 V-0 | Signal and Power | 3 | B DB | 2 | Combo D-Sub | Shielded | Gold | Free Hanging (In-Line) | Board Side (M3) | 17W2 | Flash | 20A 5A | |||||||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Copper Alloy | Receptacle Female Sockets | UL94 V-0 | Solder | Coax Signal | 4 | DC C - 17W5 | 2 | Combo D-Sub | Board Lock Shielded | Gold | Through Hole | 4-40 | Flash | 5 | 12 | |||||||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Copper Alloy | Receptacle Female Sockets | UL94 V-0 | Solder | Coax Signal | 4 | DC C - 17W5 | 2 | Combo D-Sub | Board Lock Shielded | Gold | Through Hole | Board Side (4-40) | Flash | 5 | 12 | |||||||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Copper Alloy | Receptacle Female Sockets | UL94 V-0 | Solder | Coax Signal | 4 | DC C - 17W5 | 2 | Combo D-Sub | Shielded | Gold | Through Hole | 30 Áin | 0.76 Ám | Housing/Shell (Unthreaded) | 5 | 12 | ||||||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Copper Alloy | Receptacle Female Sockets | 17 | UL94 V-0 | Solder | Signal and Power | 4 | DC C - 17W5 | 2 | Combo D-Sub | Shielded | Gold | Through Hole | Board Side (M3) | Flash | 10A 5A | |||||||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Copper Alloy | Receptacle Female Sockets | 17 | UL94 V-0 | Solder | Coax Signal | 3 | B DB | 2 | Combo D-Sub | Shielded | Gold | Through Hole | Board Side (4-40) | 17W2 | Flash | 2 | 15 Positions | |||||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Copper Alloy | Receptacle Female Sockets | 17 | UL94 V-0 | Solder | Coax Signal | 3 | B DB | 2 | Combo D-Sub | Shielded | Gold | Through Hole | Board Side (4-40) | 17W2 | Flash | 2 | 15 Positions | Nickel Plated Steel | ||||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Copper Alloy | Receptacle Female Sockets | UL94 V-0 | Solder | Coax Signal | 4 | DC C - 17W5 | 2 | Combo D-Sub | Shielded | Gold | Through Hole | Board Side (M3) | Flash | 5 | 12 | |||||||
 EDAC Inc. | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Copper Alloy | Receptacle Female Sockets | 17 | UL94 V-0 | Solder | Signal and Power | 5 A 30 A | 3 | B DB | 2 | Combo D-Sub | Shielded | Gold | Through Hole | 30 Áin | 0.76 Ám | M3 | 17W2 |
