073131 Series
Manufacturer: Molex
Beta
⌘K
BNC VERTICAL PCB
| Part | Connector Style | Center Contact Material | Center Contact Plating | Includes | Contact Termination | Housing Color | Mounting Feature | Dielectric Material | Connector Type | Fastening Type | Shield Termination | Number of Ports | Body Material | Body Finish | Impedance | Mating Cycles | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | BNC | Phosphor Bronze | Tin | 1 Connector 1 Lockwasher 1 Nut | Solder | Black Silver | Bulkhead - Front Side Nut | Polytetrafluoroethylene (PTFE) | Female Socket Jack | Bayonet Lock | Solder | 1 | Zinc Alloy | Nickel | 50 Ohms | ||
 Molex | BNC | Gold | Solder | Silver | Polytetrafluoroethylene (PTFE) | Female Socket Jack | Bayonet Lock | Solder | 1 | Brass | Nickel | 50 Ohms | 500 | Through Hole Right Angle | |||
Molex | BNC | Phosphor Bronze | Gold | Solder | Silver | Polytetrafluoroethylene (PTFE) | Female Socket Jack | Bayonet Lock | Solder | 1 | Brass | Silver | 50 Ohms | Through Hole Right Angle |
