2842247 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

40P,2MM,SHRD HDR,DRRT,SN,TB

Part	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Shape	Row Spacing - Mating	Row Spacing - Mating	Insulation Color	Shrouding	Contact Length - Post	Contact Length - Post	Insulation Material	Current Rating (Amps)	Number of Rows	Number of Positions Loaded	Style	Pitch - Mating [x]	Pitch - Mating [x]	Contact Finish - Post	Contact Length - Mating	Contact Length - Mating	Material Flammability Rating	Number of Positions	Voltage Rating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Fastening Type	Contact Material	Contact Type	Mounting Type	Termination	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions
TE Connectivity Raychem Cable Protection 4-2842247-0	78.7 µin	2 µm	Square	0.079 in	2 mm	Black	Shrouded - 4 Wall	2.5 mm	0.098 in	Thermoplastic	2 A	2	All	Board to Board Cable	0.079 in	2 mm	Tin	0.142 in	3.6 mm	UL94 V-0	40	125 VAC	2 çm	78.7 çin	Detent Lock	Copper Alloy	Male Pin	Through Hole Right Angle	Solder	Header	-40 °C	105 ░C
TE Connectivity Raychem Cable Protection 2-2842247-4	78.7 µin	2 µm	Square	0.079 in	2 mm	Black	Shrouded - 4 Wall	2.5 mm	0.098 in	Thermoplastic	2 A	2	All	Board to Board Cable	0.079 in	2 mm	Tin	0.142 in	3.6 mm	UL94 V-0	24	125 VAC	2 çm	78.7 çin	Detent Lock	Copper Alloy	Male Pin	Through Hole Right Angle	Solder	Header	-40 °C	105 ░C
TE Connectivity Raychem Cable Protection 3-2842247-0	78.7 µin	2 µm	Square	0.079 in	2 mm	Black	Shrouded - 4 Wall	2.5 mm	0.098 in	Thermoplastic	2 A	2	All	Board to Board Cable	0.079 in	2 mm	Tin	0.142 in	3.6 mm	UL94 V-0	30	125 VAC	2 çm	78.7 çin	Detent Lock	Copper Alloy	Male Pin	Through Hole Right Angle	Solder	Header	-40 °C	105 ░C
TE Connectivity Raychem Cable Protection 4-2842247-4	78.7 µin	2 µm	Square	0.079 in	2 mm	Black	Shrouded - 4 Wall	2.5 mm	0.098 in	Thermoplastic	2 A	2	All	Board to Board Cable	0.079 in	2 mm	Tin	0.142 in	3.6 mm	UL94 V-0	44	125 VAC	2 çm	78.7 çin	Detent Lock	Copper Alloy	Male Pin	Through Hole Right Angle	Solder	Header	-40 °C	105 ░C
TE Connectivity Raychem Cable Protection 3-2842247-4	78.7 µin	2 µm	Square	0.079 in	2 mm	Black	Shrouded - 4 Wall	2.5 mm	0.098 in	Thermoplastic	2 A	2	All	Board to Board Cable	0.079 in	2 mm	Tin	0.142 in	3.6 mm	UL94 V-0	34	125 VAC	2 çm	78.7 çin	Detent Lock	Copper Alloy	Male Pin	Through Hole Right Angle	Solder	Header	-40 °C	105 ░C
TE Connectivity Raychem Cable Protection 1-2842247-6	78.7 µin	2 µm	Square	0.079 in	2 mm	Black	Shrouded - 4 Wall	2.5 mm	0.098 in	Thermoplastic	2 A	2	All	Board to Board Cable	0.079 in	2 mm	Tin	0.142 in	3.6 mm	UL94 V-0		125 VAC	2 çm	78.7 çin	Detent Lock	Copper Alloy	Male Pin	Through Hole Right Angle	Solder	Header	-40 °C	105 ░C	16
