GRSE18 Series

Catalog

PHOTOELECTRIC SENSOR, 15M, NPN, 10-30V ROHS COMPLIANT: YES

Part	Output Configuration	Sensing Method	Cable Length	Cable Length	Connection Method	Sensing Distance	Sensing Distance	Response Time	Voltage - Supply [Min]	Voltage - Supply [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Light Source	Adjustment Type	Ingress Protection	Sensing Distance
SICK, Inc. GRSE18-N1142	NPN	Through-Beam	78.74 "	2 m	Cable	590.551 in	15 m	500 µs	10 VDC	30 VDC	-25 °C	55 °C	RED (650nm)	Adjustable Potentiometer	IP67
SICK, Inc. 1067983	NPN	Through-Beam			Connector M12		393.701 in	500 µs	10 VDC	30 VDC	-25 °C	55 °C	RED (650nm)	Adjustable Potentiometer	IP67	10 m
SICK, Inc. GRSE18-P2447	PNP	Through-Beam			Connector M12		393.701 in	500 µs	10 VDC	30 VDC	-25 °C	55 °C	RED (650nm)	Adjustable Potentiometer	IP67	10 m
SICK, Inc. 1067984	PNP	Through-Beam	78.74 "	2 m	Cable	590.551 in	15 m	500 µs	10 VDC	30 VDC	-25 °C	55 °C	RED (650nm)	Adjustable Potentiometer	IP67
SICK, Inc. 1068334	NPN	Through-Beam	78.74 "	2 m	Cable	590.551 in	15 m	500 µs	10 VDC	30 VDC	-25 °C	55 °C	Infrared (880nm)	Adjustable Potentiometer	IP67
SICK, Inc. 1068335	NPN	Through-Beam			Connector M12	590.551 in	15 m	500 µs	10 VDC	30 VDC	-25 °C	55 °C	Infrared (880nm)	Adjustable Potentiometer	IP67
SICK, Inc. 1066558	NPN	Through-Beam	78.74 "	2 m	Cable	590.551 in	15 m	500 µs	10 VDC	30 VDC	-25 °C	55 °C	RED (650nm)	Adjustable Potentiometer	IP67
SICK, Inc. 1067985	NPN	Through-Beam			Connector M12	590.551 in	15 m	500 µs	10 VDC	30 VDC	-25 °C	55 °C	RED (650nm)	Adjustable Potentiometer	IP67
SICK, Inc. GRSE18-P2442	PNP	Through-Beam			Connector M12	590.551 in	15 m	500 µs	10 VDC	30 VDC	-25 °C	55 °C	RED (650nm)	Adjustable Potentiometer	IP67
SICK, Inc. 1068331	NPN	Through-Beam	78.74 "	2 m	Cable	590.551 in	15 m	500 µs	10 VDC	30 VDC	-25 °C	55 °C	Infrared (880nm)	Adjustable Potentiometer	IP67
