892-044 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 44POS 0.100
| Part | Material - Insulation | Termination Rows | Number of Rows | Termination | Contact Finish | Contact Type | Gender | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Mounting Type | Number of Positions/Bay/Row | Color | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Number of Positions | Card Type | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Termination Rows [custom] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 1 | Solder | Gold | Cantilever | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Through Hole | 44 | Black | 125 °C | -40 C | Single | 44 | Non Specified - Single Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Gold | Cantilever | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | 22 | Black | 125 °C | -40 C | Dual | 44 | Non Specified - Dual Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 2 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 1 | Wire Wrap | Gold | Cantilever | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Through Hole | 44 | Black | 125 °C | -40 C | Single | 44 | Non Specified - Single Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Gold | Cantilever | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Through Hole | 22 | Black | 125 °C | -40 C | Dual | 44 | Non Specified - Dual Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 1 | Solder | Gold | Cantilever | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Through Hole | 44 | Black | 125 °C | -40 C | Single | 44 | Non Specified - Single Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 1 | Wire Wrap | Gold | Cantilever | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | 44 | Black | 125 °C | -40 C | Single | 44 | Non Specified - Single Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 1 | Solder | Gold | Cantilever | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Flush Mount M3 Threaded Insert Top Opening | Through Hole | 44 | Black | 125 °C | -40 C | Single | 44 | Non Specified - Single Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Gold | Cantilever | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Through Hole | 22 | Black | 125 °C | -40 C | Dual | 44 | Non Specified - Dual Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Gold | Cantilever | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Right Angle Through Hole | 22 | Black | 125 °C | -40 C | Dual | 44 | Non Specified - Dual Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Solder | Gold | Cantilever | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | 22 | Black | 125 °C | -40 C | Dual | 44 | Non Specified - Dual Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 2 |
