807-012 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 24POS 0.156
...
| Part | Gender | Termination | Termination Rows | Number of Rows | Contact Finish | Card Type | Number of Positions/Bay/Row [custom] | Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Pitch [x] | Pitch [x] | Mounting Type | Flange Feature | Flange Feature | Flange Feature | Number of Positions | Read Out | Material - Insulation | Color | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Female | Solder | 1 | 2 | Tin | Non Specified - Dual Edge | 12 | Semi Bellows | 125 °C | -40 °C | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Through Hole | Side Mount Opening Unthreaded | 3.25 mm | 0.128 in | 24 | Dual | Diallyl Phthalate (DAP) | Green | ||||
 EDAC Inc. | Female | Solder | 1 | 2 | Tin | Non Specified - Dual Edge | 12 | Semi Bellows | 125 °C | -40 °C | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Through Hole Right Angle | Flush Mount M3 Threaded Insert Top Opening | 24 | Dual | Diallyl Phthalate (DAP) | Green | ||||||
 EDAC Inc. | Female | Solder | 2 | 2 | Gold | Non Specified - Dual Edge | 6 | Semi Bellows | 125 °C | -40 °C | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Through Hole Right Angle | Flush Mount Top Opening Unthreaded | 12 | Single | Diallyl Phthalate (DAP) | Green | 10 Áin | 0.25 Ám | 3.96 mm | 0.156 in | ||
 EDAC Inc. | Female | Wire Wrap | 1 | 1 | Tin | Non Specified - Single Edge | 12 | Semi Bellows | 125 °C | -40 °C | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 12 | Single | Diallyl Phthalate (DAP) | Green | ||||||
EDAC Inc. | Female | Wire Wrap | 2 | 2 | Tin | Non Specified - Dual Edge | 6 | Semi Bellows | 125 °C | -40 °C | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 12 | Dual | Diallyl Phthalate (DAP) | Green | ||||||
 EDAC Inc. | Female | Solder | 1 | 2 | Gold | Non Specified - Dual Edge | 12 | Semi Bellows | 125 °C | -40 °C | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Through Hole Right Angle | 4-40 Flush Mount Threaded Insert Top Opening | 24 | Dual | Diallyl Phthalate (DAP) | Green | 10 Áin | 0.25 Ám | ||||
 EDAC Inc. | Female | Wire Wrap | 1 | 1 | Gold | Non Specified - Single Edge | 12 | Semi Bellows | 125 °C | -40 °C | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Through Hole | Flush Mount Top Opening Unthreaded | 12 | Single | Diallyl Phthalate (DAP) | Green | 10 Áin | 0.25 Ám | 3.25 mm | 0.128 " | ||
 EDAC Inc. | Female | Solder | 2 | 2 | Tin | Non Specified - Dual Edge | 6 | Semi Bellows | 125 °C | -40 °C | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Through Hole Right Angle | 12 | Single | Diallyl Phthalate (DAP) | Green | |||||||
 EDAC Inc. | Female | Wire Wrap | 1 | 1 | Gold | Non Specified - Single Edge | 12 | Semi Bellows | 125 °C | -40 °C | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Through Hole | 12 | Single | Diallyl Phthalate (DAP) | Green | 10 Áin | 0.25 Ám | |||||
 EDAC Inc. | Female | Solder | 1 | 2 | Gold | Non Specified - Dual Edge | 12 | Semi Bellows | 125 °C | -40 °C | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Through Hole Right Angle | Flush Mount Top Opening Unthreaded | 24 | Dual | Diallyl Phthalate (DAP) | Green | 10 Áin | 0.25 Ám | 3.25 mm | 0.128 " |
