SFV10R Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN FPC TOP 10POS 0.5MM R/A
| Part | Housing Color | Current Rating (Amps) | Mating Cycles | Actuator Color | Pitch | Pitch | FFC, FCB Thickness | Voltage Rating | Connector/Contact Type | Number of Positions | Termination | Locking Feature | Flat Flex Type | Mounting Type | Cable End Type | Height Above Board [z] | Height Above Board [z] | Actuator Material | Contact Material | Housing Material | Contact Finish | Material Flammability Rating | Operating Temperature [Min] | Operating Temperature [Max] | Features | FFC, FCB Thickness [custom] | FFC, FCB Thickness [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | Black | 0.5 A | 20 | Brown | 0.02 " | 0.5 mm | 0.33 mm | 50 V | Contacts Top | 10 | Solder | Slide Lock | FPC | Right Angle Surface Mount | Tapered | 0.071 in | 1.8 mm | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Phosphor Bronze | Glass Filled Halogen Free Nylon Polyamide (PA) | Gold | UL94 V-0 | -55 C | 105 ░C | |||
 Amphenol ICC (FCI) | Black | 0.5 A | 20 | Black | 0.02 " | 0.5 mm | 0.3 mm | 50 V | Contacts Top | 10 | Solder | Slide Lock | FFC FPC | Right Angle Surface Mount | Tapered | 0.071 in | 1.8 mm | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Phosphor Bronze | Glass Filled Halogen Free Nylon Polyamide (PA) | Gold | UL94 V-0 | -55 C | 105 ░C | |||
 Amphenol ICC (FCI) | Black | 0.5 A | 20 | Black | 0.02 " | 0.5 mm | 0.33 mm | 50 V | Contacts Top | 10 | Solder | Slide Lock | FFC FPC | Right Angle Surface Mount | Tapered | 0.071 in | 1.8 mm | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Phosphor Bronze | Glass Filled Halogen Free Nylon Polyamide (PA) | Gold | UL94 V-0 | -55 C | 105 ░C | |||
 Amphenol ICC (FCI) | Black | 0.5 A | 20 | Beige | 0.02 " | 0.5 mm | 0.3 mm | 50 V | Contacts Bottom | 10 | Solder | Slide Lock | FPC | Right Angle Surface Mount | Tapered | 0.071 in | 1.8 mm | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Phosphor Bronze | Glass Filled Halogen Free Nylon Polyamide (PA) | Gold | UL94 V-0 | -55 C | 105 ░C | |||
Amphenol ICC (FCI) | 0.02 " | 0.5 mm | Contacts Bottom | 10 | Solder | Slide Lock | Right Angle Surface Mount | ||||||||||||||||||||
 Amphenol ICC (FCI) | Black | 0.5 A | 20 | Brown | 0.02 " | 0.5 mm | 50 V | Contacts Bottom | 10 | Solder | Slide Lock | FFC FPC | Right Angle Surface Mount | Straight Tapered | 0.071 in | 1.8 mm | Polyphenylene Sulfide (PPS) Glass Filled | Phosphor Bronze | Glass Filled Nylon Polyamide (PA) | Tin Alloy | UL94 V-0 | -55 C | 105 ░C | Solder Retention Zero Insertion Force (ZIF) | 0.3 mm | 0.33 mm | |
 Amphenol ICC (FCI) | Black | 0.5 A | 20 | Black | 0.02 " | 0.5 mm | 50 V | Contacts Bottom | 10 | Solder | Slide Lock | FFC FPC | Right Angle Surface Mount | Straight Tapered | 0.071 in | 1.8 mm | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Phosphor Bronze | Glass Filled Halogen Free Nylon Polyamide (PA) | Tin | UL94 V-0 | -55 C | 105 ░C | Solder Retention Zero Insertion Force (ZIF) | 0.3 mm | 0.33 mm | |
 Amphenol ICC (FCI) | Black | 0.5 A | 20 | Black | 0.02 " | 0.5 mm | 0.3 mm | 50 V | Contacts Bottom | 10 | Solder | Slide Lock | FFC FPC | Right Angle Surface Mount | Tapered | 0.071 in | 1.8 mm | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Phosphor Bronze | Glass Filled Halogen Free Nylon Polyamide (PA) | Gold | UL94 V-0 | -55 C | 105 ░C | Solder Retention Zero Insertion Force (ZIF) | ||
Amphenol ICC (FCI) | Black | 0.5 A | 20 | Black | 0.02 " | 0.5 mm | 50 V | Contacts Top | 10 | Solder | Slide Lock | FFC FPC | Right Angle Surface Mount | Straight Tapered | 0.071 in | 1.8 mm | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Phosphor Bronze | Glass Filled Halogen Free Nylon Polyamide (PA) | Tin | UL94 V-0 | -55 C | 105 ░C | Solder Retention Zero Insertion Force (ZIF) | 0.3 mm | 0.33 mm | |
 Amphenol ICC (FCI) | Black | 0.5 A | 20 | Brown | 0.02 " | 0.5 mm | 50 V | Contacts Top | 10 | Solder | Slide Lock | FPC | Right Angle Surface Mount | Notched | 0.071 in | 1.8 mm | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Phosphor Bronze | Glass Filled Halogen Free Nylon Polyamide (PA) | Tin | UL94 V-0 | -55 C | 105 ░C | 0.3 mm | 0.33 mm |
