8410 Series
Manufacturer: Belden Inc.
Beta
⌘K
#25 EPDM BRD EPDM
| Part | Conductor Material | Dielectric Material | Shield Material | Shield Coverage | Dielectric Diameter [diameter] | Dielectric Diameter [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Impedance | Jacket Color | Shield Type | Cable Type | Usage | Wire Gauge | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Material | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Copper Tinned Steel Copper Covered Tin Coated | Ethylene Propylene Terpolymer Rubber (EPDM) | Copper Tinned Rayon® | 80 % | 3.91 mm | 0.154 in | -30 ░C | 60 °C | 52 Ohms | Black | Double Braid | Coaxial | Audio | 25 AWG | 7 Strands | 33 AWG | 0.245 " | 6.22 mm | Ethylene Propylene Terpolymer Rubber (EPDM) | 152.4 m | 500 ft |
