A12 Series
Manufacturer: Century Spring Corp
Beta
⌘K
COMPRESSION STEEL 0.406" 0.540"
| Part | Finish | Material | End Style | Wire Diameter [diameter] | Wire Diameter [diameter] | Rate | Type | Diameter - Inside [diameter] | Diameter - Inside [diameter] | Diameter - Outside [diameter] | Diameter - Outside [diameter] | Free Length | Free Length | Diameter - Outside [diameter] | Free Length [custom] | Free Length [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Century Spring Corp | None | Stainless Steel | Closed | 0.021 in | 0.53 mm | 2.1 lbs/in | Compression | 0.364 in | 9.25 mm | 0.406 in | 10.31 mm | 0.54 " | 13.72 mm | |||
 Century Spring Corp | Zinc | Music Wire | Closed | 0.022 in | 0.56 mm | 1.2 lbs/in | Compression | 0.346 " | 8.79 mm | 9.91 mm | 0.97 " | 24.64 mm | 0.39 in | |||
 Century Spring Corp | None | Stainless Steel | Closed | 0.014 in | 0.36 mm | 4 lbs/in | Compression | 0.112 in | 2.84 mm | 3.56 mm | 0.14 in | 8.89 mm | 0.35 " |
