395-094 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 94POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Contact Material | Contact Finish | Read Out | Number of Positions | Pitch | Pitch | Color | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Gender | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Mounting Type | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Termination | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Gold | Dual | 94 | 0.1 " | 2.54 mm | Black | Cantilever | 0.25 Ám | 10 Áin | 47 | Female | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Right Angle Through Hole | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Gold | Dual | 94 | 0.1 " | 2.54 mm | Black | Cantilever | 0.25 Ám | 10 Áin | 47 | Female | 4-40 Threaded Insert Top Mount Opening | Right Angle Through Hole | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Gold | Dual | 94 | 0.1 " | 2.54 mm | Black | Cantilever | 0.25 Ám | 10 Áin | 47 | Female | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Through Hole | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Gold | Dual | 94 | 0.1 " | 2.54 mm | Black | Cantilever | 0.25 Ám | 10 Áin | 47 | Female | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Right Angle Through Hole | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Gold | Dual | 94 | 0.1 " | 2.54 mm | Black | Cantilever | 0.25 Ám | 10 Áin | 47 | Female | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Through Hole | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Gold | Dual | 94 | 0.1 " | 2.54 mm | Black | Cantilever | 0.25 Ám | 10 Áin | 47 | Female | 4-40 Threaded Insert Top Mount Opening | Through Hole | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Gold | Dual | 94 | 0.1 " | 2.54 mm | Black | Cantilever | 0.25 Ám | 10 Áin | 47 | Female | 4-40 Threaded Insert Top Mount Opening | Through Hole | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Gold | Dual | 94 | 0.1 " | 2.54 mm | Black | Cantilever | 0.25 Ám | 10 Áin | 47 | Female | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Through Hole | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Gold | Dual | 94 | 0.1 " | 2.54 mm | Black | Cantilever | 0.25 Ám | 10 Áin | 47 | Female | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Board Edge Straddle Mount | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Gold | Dual | 94 | 0.1 " | 2.54 mm | Black | Cantilever | 0.25 Ám | 10 Áin | 47 | Female | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Through Hole | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder |
