HES.2M Series
Manufacturer: LEMO
Beta
⌘K
CONN RCPT MALE 10POS GOLD SOLDER
| Part | Features | Shielding | Mounting Feature | Operating Temperature [Max] | Operating Temperature [Min] | Color | Number of Positions | Contact Material | Contact Finish - Mating | Current Rating (Amps) | Primary Material | Shell Material | Insert Material | Applications | Connector Type | Orientation | Mounting Type | Shell Size - Insert | Termination | Shell Finish | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Fastening Type | Ingress Protection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LEMO | Potted | Shielded | Bulkhead - Front Side Nut | 80 °C | -20 ░C | Gray | 10 | Brass | Gold | 8 A | Metal | Aluminum Alloy | Polyetheretherketone (PEEK) | Aerospace Automotive Aviation Military | Receptacle Male Pins | S | Panel Mount Through Hole | 310 | Solder | Nickel | 39.4 µin | 1 µm | Threaded | IP68 - Dust Tight Waterproof |
 LEMO | Potted | Shielded | Bulkhead - Front Side Nut | 80 °C | -20 ░C | Gray | 19 | Brass | Gold | 4 A | Metal | Aluminum Alloy | Polyetheretherketone (PEEK) | Aerospace Automotive Aviation Military | Receptacle Male Pins | S | Panel Mount Through Hole | 319 | Solder | Nickel | 39.4 µin | 1 µm | Threaded | IP68 - Dust Tight Waterproof |
