147-0701 Series
Manufacturer: Cinch Connectivity Solutions Johnson
Beta
⌘K
2.4MM END LAUNCH JACK FOR .042"
| Part | Body Finish | Mating Cycles | Voltage Rating | Operating Temperature [Max] | Operating Temperature [Min] | Body Material | Dielectric Material | Center Contact Plating | Contact Termination | Center Contact Material | Connector Type | Impedance | Connector Style [x] | Connector Style | Connector Style | Fastening Type | Housing Color | Frequency - Max [Max] | Number of Ports | Shield Termination | Mounting Type | Mounting Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cinch Connectivity Solutions Johnson | Gold | 500 | 150 VDC | 85 °C | -40 C | Brass | Polytetrafluoroethylene (PTFE) | Gold | Solder | Beryllium Copper | Female Socket Jack | 50 Ohms | 2.4 mm | OS-50 | APC-2.4 | Threaded | Gold | 50 GHz | 1 | Solder | Board Edge End Launch | ||
 Cinch Connectivity Solutions Johnson | 500 | 165 °C | -65 ░C | Stainless Steel | Polytetrafluoroethylene (PTFE) | Gold | Solder | Beryllium Copper | Female Socket Jack | 50 Ohms | 2.4 mm | OS-50 | APC-2.4 | Threaded | Silver | 50 GHz | 1 | Screw | Surface Mount | Flange | Mounting Hardware | ||
 Cinch Connectivity Solutions Johnson | 500 | 125 °C | -55 C | Stainless Steel | Polytetrafluoroethylene (PTFE) | Gold | Solder | Beryllium Copper | Female Socket Jack | 50 Ohms | 2.4 mm | OS-50 | APC-2.4 | Threaded | Silver | 50 GHz | 1 | Screw | Board Edge End Launch | Mounting Hardware | |||
 Cinch Connectivity Solutions Johnson | Gold | 500 | 150 VDC | 85 °C | -40 C | Brass | Polytetrafluoroethylene (PTFE) | Gold | Solder | Beryllium Copper | Female Socket Jack | 50 Ohms | 2.4 mm | OS-50 | APC-2.4 | Threaded | Gold | 50 GHz | 1 | Solder | Board Edge End Launch Right Angle Through Hole | ||
 Cinch Connectivity Solutions Johnson | Gold | 500 | 150 VDC | 85 °C | -40 C | Brass | Polytetrafluoroethylene (PTFE) | Gold | Solder | Beryllium Copper | Female Socket Jack | 50 Ohms | 2.4 mm | OS-50 | APC-2.4 | Threaded | Gold | 50 GHz | 1 | Solder | Board Edge End Launch | ||
Cinch Connectivity Solutions Johnson | 500 | 125 °C | -55 C | Stainless Steel | Polytetrafluoroethylene (PTFE) | Gold | Solder | Beryllium Copper | Female Socket Jack | 50 Ohms | 2.4 mm | OS-50 | APC-2.4 | Threaded | Silver | 50 GHz | 1 | Screw | Board Edge End Launch | Mounting Hardware | |||
 Cinch Connectivity Solutions Johnson | Gold | 500 | 150 VDC | 85 °C | -40 C | Brass | Polytetrafluoroethylene (PTFE) | Gold | Solder | Beryllium Copper | Female Socket Jack | 50 Ohms | 2.4 mm | OS-50 | APC-2.4 | Threaded | Gold | 50 GHz | 1 | Solder | Board Edge End Launch |
