306-015 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 30POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row | Color | Number of Positions | Number of Rows [custom] | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Card Type | Termination | Gender | Pitch | Pitch | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Read Out |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 15 | Green | 30 | 2 | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount | Non Specified - Dual Edge | Solder Eyelet(s) | Female | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Tin | Dual |
 EDAC Inc. | Polyester Thermoplastic | 1 | 15 | Green | 30 | 2 | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Non Specified - Dual Edge | Solder | Female | 3.96 mm | 0.156 in | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Tin | Dual |
 EDAC Inc. | Polyester Thermoplastic | 1 | 15 | Green | 30 | 2 | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount | Non Specified - Dual Edge | Solder Eyelet(s) | Female | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Tin | Dual |
 EDAC Inc. | Polyester Thermoplastic | 1 | 15 | Green | 30 | 2 | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Non Specified - Dual Edge | Solder | Female | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Tin | Dual | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 15 | Green | 30 | 2 | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Free Hanging (In-Line) | Non Specified - Dual Edge | Solder Eyelet(s) | Female | 3.96 mm | 0.156 in | Tin | Dual | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 15 | Green | 30 | 2 | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Dual Edge | Solder | Female | 3.96 mm | 0.156 in | Tin | Dual | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 15 | Green | 30 | 2 | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount | Non Specified - Dual Edge | Solder Eyelet(s) | Female | 3.96 mm | 0.156 in | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Tin | Dual |
 EDAC Inc. | Polyester Thermoplastic | 1 | 15 | Green | 30 | 2 | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Dual Edge | Solder | Female | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Gold | Dual |
 EDAC Inc. | Polyester Thermoplastic | 1 | 15 | Green | 30 | 2 | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Non Specified - Dual Edge | Solder | Female | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Tin | Dual |
 EDAC Inc. | Polyester Thermoplastic | 1 | 15 | Green | 30 | 2 | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount | Non Specified - Dual Edge | Solder Eyelet(s) | Female | 3.96 mm | 0.156 in | Flush Mount M3 Threaded Insert Top Opening | Tin | Dual |
