SCA7PT78 Series
Manufacturer: Samsung Semiconductor, Inc.
Beta
⌘K
LED LH309A COOL WHT 6500K 12CSP
| Part | Thermal Resistance of Package | Lumens/Watt @ Current - Test | Height - Seated (Max) [Max] | Height - Seated (Max) | CRI (Color Rendering Index) | Package / Case | Current - Test | CCT (K) | Viewing Angle | Supplier Device Package | Color | Voltage - Forward (Vf) (Typ) | Flux @ 85°C, Current - Test [Min] | Flux @ 85°C, Current - Test [Max] | Mounting Type | Current - Max [Max] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Samsung Semiconductor, Inc. | 1.2 °C/W | 146 lm/W | 0.016 in | 0.4 mm | 70 | 2020 (5050 Metric) | 150 mA | 6500 K | 120 ° | 12-CSP | Cool White | 26 V | 510 lm | 625 lm | Surface Mount | 250 mA | 0.197 in | 0.197 " | 5 mm | 5 mm |
