ULT-5 Series
Manufacturer: Murata Electronics
Beta
⌘K
DC DC CONVERTER 5V 25W
| Part | Type | Operating Temperature [Max] | Operating Temperature [Min] | Features | Voltage - Input (Max) [Max] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Power (Watts) | Control Features | Efficiency | Number of Outputs | Package / Case | Voltage - Isolation | Voltage - Output 1 | Applications | Voltage - Input (Min) [Min] | Current - Output (Max) | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Murata Electronics | Isolated Module | 85 °C | -40 C | Remote On/Off UVLO | 75 V | 8.9 mm | 23.4 mm | 19.1 mm | 0.75 in | 0.92 " | 0.35 in | 25 W | Active High Enable | 89 % | 1 | 8-DIP Module 1/32 Brick | 1.5 kV | 5 V | ITE (Commercial) | 36 V | 5 A | Through Hole |
Murata Electronics | Isolated Module | 85 °C | -40 C | Remote On/Off UVLO | 75 V | 8.9 mm | 23.4 mm | 19.1 mm | 0.75 in | 0.92 " | 0.35 in | 25 W | Active High Enable | 89 % | 1 | 8-SMD Module 1/32 Brick | 1.5 kV | 5 V | ITE (Commercial) | 36 V | 5 A | Surface Mount |
Murata Electronics | Isolated Module | 85 °C | -40 C | Remote On/Off UVLO | 75 V | 8.9 mm | 23.4 mm | 19.1 mm | 0.75 in | 0.92 " | 0.35 in | 25 W | Active Low Enable | 89 % | 1 | 8-DIP Module 1/32 Brick | 1.5 kV | 5 V | ITE (Commercial) | 36 V | 5 A | Through Hole |
