VI-271 Series

Catalog

DC-DC REGULATED POWER SUPPLY MODULE, 100W

Part	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Current - Output (Max) [Max]	Voltage - Isolation	Package / Case	Number of Outputs	Voltage - Input (Min) [Min]	Features	Efficiency	Voltage - Input (Max) [Max]	Mounting Type	Voltage - Output 1	Type	Operating Temperature [Min]	Operating Temperature [Max]	Power (Watts)	Applications
Vicor Corporation VI-271-EW-B1	61 mm	27.1 mm	116.8 mm	1.07 "	2.4 "	4.6 "	8.33 A	3000 V	Full Brick	1	100 VDC	OCP OTP OVP SCP	88 %	375 V	Through Hole	12 V	Isolated Module	-10 °C	85 °C	100 W	ITE (Commercial)
Vicor Corporation VI-271-IX	61 mm	12.7 mm	116.8 mm	0.5 in	2.4 "	4.6 "	6.25 A	3000 V	Full Brick	1	100 VDC	OCP OTP OVP SCP	90 %	375 V	Through Hole	12 V	Isolated Module	-40 °C	85 °C	75 W	ITE (Commercial)
Vicor Corporation VI-271-CW	61 mm	12.7 mm	116.8 mm	0.5 in	2.4 "	4.6 "	8.33 A	3000 V	Full Brick	1	100 VDC	OCP OTP OVP SCP	90 %	375 V	Through Hole	12 V	Isolated Module	-25 °C	85 °C	100 W	ITE (Commercial)
Vicor Corporation VI-271-EW	61 mm	12.7 mm	116.8 mm	0.5 in	2.4 "	4.6 "	8.33 A	3000 V	Full Brick	1	100 VDC	OCP OTP OVP SCP	88 %	375 V	Through Hole	12 V	Isolated Module	-10 °C	85 °C	100 W	ITE (Commercial)
Vicor Corporation VI-271-EX	61 mm	12.7 mm	116.8 mm	0.5 in	2.4 "	4.6 "	6.25 A	3000 V	Full Brick	1	100 VDC	OCP OTP OVP SCP	88 %	375 V	Through Hole	12 V	Isolated Module	-10 °C	85 °C	75 W	ITE (Commercial)
