Phone Connectors 3C RT ANG 1/4\/
Phone Connectors 3C RT ANG 1/4\/
| Part | Current Rating (Amps) | Voltage - Rated | Contact Material | Thread Size | Panel Hole Size | Panel Hole Size | Housing Material | Body Color | Contact Material - Plating | Includes | Termination | Internal Switch(s) | Mounting Type | Connector Type | Features | Actual Diameter [diameter] | Actual Diameter [diameter] | Gender | Number of Positions/Contacts [custom] | Number of Positions/Contacts [custom] | Signal Lines | Shielding | Body Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SWITCHCRAFT/CONXALL | 0.25 A | 48 VDC | Brass | 3/8"-32 | 9.52 mm | 0.375 in | Polyester Glass Filled | Black | Tin | 1 Nut 1 Washer 3 pcs - 1 Connector | Solder Eyelet(s) | Single Switch | Panel Mount Through Hole | Phone Jack | Mounting Hardware Thread Lock | 0.25 in | 6.35 mm | Female | 4 | 3 | Stereo (3 Conductor TRS) | Unshielded | |
 SWITCHCRAFT/CONXALL | Solder | Single Switch | Panel Mount Through Hole | Phone Jack | Mounting Hardware Thread Lock | 0.25 in | 6.35 mm | Female | 3 | 2 | Mono | Unshielded | |||||||||||
 SWITCHCRAFT/CONXALL | 0.25 A | 48 VDC | Brass | 3/8"-32 | 9.52 mm | 0.375 in | Polyester Glass Filled | Black | Tin | 1 Nut 1 Washer 3 pcs - 1 Connector | Solder Eyelet(s) | Single Switch | Panel Mount Through Hole | Phone Jack | Mounting Hardware Thread Lock | 0.25 in | 6.35 mm | Female | 4 | 2 | Mono | Unshielded | |
 SWITCHCRAFT/CONXALL | Copper Alloy | 3/8"-32 | 9.52 mm | 0.375 in | Thermoplastic | Black | Silver | 1 Nut 1 Washer 3 pcs - 1 Connector | Solder | Single Switch | Right Angle Through Hole | Phone Jack | Mounting Hardware | Female | 4 | 3 | Stereo (3 Conductor TRS) | Unshielded | |||||
 SWITCHCRAFT/CONXALL | 0.25 A | 48 VDC | Brass | 3/8"-32 | 9.52 mm | 0.375 in | Polyester Glass Filled | Black Silver | Tin | 1 Nut 1 Washer 3 pcs - 1 Connector | Solder Eyelet(s) | Two Switches | Panel Mount | Phone Jack | Mounting Hardware Thread Lock | 0.25 in | 6.35 mm | Female | 5 | 3 | Stereo (3 Conductor TRS) | Unshielded | Brass |
