BSC0909 Series
Manufacturer: INFINEON
Beta
⌘K
OPTIMOS™ N-CHANNEL POWER MOSFET 30 V ; SUPERSO8 5X6 PACKAGE; 11.8 MOHM;
| Part | Gate Charge (Qg) (Max) @ Vgs | Input Capacitance (Ciss) (Max) @ Vds [Max] | FET Type | Technology | Vgs(th) (Max) @ Id | Rds On (Max) @ Id, Vgs | Operating Temperature [Max] | Operating Temperature [Min] | Vgs (Max) | Current - Continuous Drain (Id) @ 25°C | Supplier Device Package | Mounting Type | Package / Case | Drive Voltage (Max Rds On, Min Rds On) | Drain to Source Voltage (Vdss) | Power Dissipation (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 INFINEON | 15 nC | 1110 pF | N-Channel | MOSFET (Metal Oxide) | 2 V | 9.2 mOhm | 150 °C | -55 °C | 20 V | 12 A 44 A | PG-TDSON-8-5 | Surface Mount | 8-PowerTDFN | 4.5 V 10 V | 34 V | 2.5 W 27 W |
