773-E15 Series
Manufacturer: NorComp Inc.
Beta
⌘K
IP67 15 / .318 /141 ROHS COMPLIANT: YES
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Color | Dielectric Material | Contact Material | Shell Material, Finish | Number of Positions | Contact Type | Current Rating (Amps) | Contact Finish | Material Flammability Rating | Flange Feature | Number of Rows [custom] | Backset Spacing | Backset Spacing | Termination | Connector Style | Mounting Type | Shell Size, Connector Layout | Contact Finish Thickness | Ingress Protection | Connector Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | 100 °C | -50 °C | White | Polyamide (PA6T) Nylon 6T | Brass | Nickel Plated Steel | 15 | Signal | 5 A | Gold | UL94 V-0 | 4-40 Mating Side Female Screwlock | 2 | 7.2 mm | 0.283 in | Solder | D-Sub | Panel Mount Right Angle Through Hole | 2 | Flash | IP67 - Dust Tight Waterproof | Receptacle Female Sockets | Mounting Brackets |
 NorComp Inc. | 100 °C | -50 °C | White | Polyamide (PA6T) Nylon 6T | Brass | Nickel Plated Steel | 15 | Signal | 5 A | Gold | UL94 V-0 | Housing/Shell (Unthreaded) | 2 | 7.2 mm | 0.283 in | Solder | D-Sub | Panel Mount Right Angle Through Hole | 2 | Flash | IP67 - Dust Tight Waterproof | Plug Male Pins | Grounding Indents |
