Reed Relays HV RELAYS
Reed Relays HV RELAYS
| Part | Contact Form | Coil Type | Must Release Voltage | Operating Temperature [Max] | Operating Temperature [Min] | Termination Style | Contact Rating (Current) | Contact Material | Coil Voltage | Mounting Type | Coil Current | Must Operate Voltage | Switching Voltage [Max] | Operate Time | Release Time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | SPST-NO (1 Form A) | Non Latching | 4 VDC | 85 °C | -40 C | PC Pin | 1 A | Rhodium (Rh) | 24 VDC | Through Hole | 15.5 mA | 19 VDC | 300 VAC 350 VDC | 1 ms | 0.5 ms |
 Sensata-Crydom | SPST-NO (1 Form A) | Non Latching | 1 VDC | 85 °C | -40 C | PC Pin | 1 A | Rhodium (Rh) | 5 VDC | Through Hole | 41.7 mA | 4 VDC | 300 VAC 350 VDC | 1 ms | 0.5 ms |
Sensata-Crydom | SPST-NO (1 Form A) | Non Latching | 4 VDC | 85 °C | -40 C | PC Pin | 1 A | Rhodium (Rh) | 24 VDC | Through Hole | 15.5 mA | 19 VDC | 1000 VAC 1000 VDC | 1 ms | 0.5 ms |
Sensata-Crydom | SPST-NO (1 Form A) | Non Latching | 1 VDC | 85 °C | -40 C | PC Pin | 1 A | Rhodium (Rh) | 5 VDC | Through Hole | 41.7 mA | 4 VDC | 1000 VAC 1000 VDC | 1 ms | 0.5 ms |
 Sensata-Crydom | SPST-NO (1 Form A) | Non Latching | 2 VDC | 85 °C | -40 C | PC Pin | 1 A | Rhodium (Rh) | 12 VDC | Through Hole | 16 mA | 9.6 VDC | 300 VAC 350 VDC | 1 ms | 0.5 ms |
 Sensata-Crydom | SPST-NO (1 Form A) | Non Latching | 2 VDC | 85 °C | -40 C | PC Pin | 1 A | Rhodium (Rh) | 12 VDC | Through Hole | 16 mA | 9.6 VDC | 1000 VAC 1000 VDC | 1 ms | 0.5 ms |
