628W5W Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB RCPT 5P PNL MNT SLDR
| Part | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Color | Dielectric Material | Voltage Rating | Current Rating (Amps) | Features | Mounting Type | Connector Style | Contact Finish Thickness | Contact Finish Thickness | Termination | Material Flammability Rating | Contact Type | Number of Rows [custom] | Ingress Protection | Contact Finish | Connector Type | Flange Feature | Flange Feature | Shell Size, Connector Layout | Shell Size, Connector Layout | Shell Material, Finish | Number of Positions | Shell Size, Connector Layout [x] | Shell Size, Connector Layout [custom] | Number of Rows | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | 85 °C | -25 °C | Black | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | 5 A 30 A | Shielded | Panel Mount Through Hole | Combo D-Sub | 30 Áin | 0.76 Ám | Solder | UL94 V-0 | Signal and Power | 2 | IP67 - Dust Tight Waterproof | Gold | Receptacle Female Sockets | Housing/Shell | 4-40 | 1 | 5W1 DE E | Nickel Plated Steel | 5 | ||||
 EDAC Inc. | Copper Alloy | 85 °C | -25 °C | Black | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | 10 A | Board Lock Shielded | Panel Mount | Combo D-Sub | 30 Áin | 0.76 Ám | Solder | UL94 V-0 | Power | IP67 - Dust Tight Waterproof | Gold | Receptacle Female Sockets | Board Side (4-40) | 5W5 | Nickel Plated Steel | 5 | 3 | DB B | 1 | ||||
 EDAC Inc. | Copper Alloy | 85 °C | -25 °C | Black | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | 20 A | Shielded | Panel Mount | Combo D-Sub | 15 µin | 0.38 µm | Solder | UL94 V-0 | Power | IP67 - Dust Tight Waterproof | Gold | Receptacle Female Sockets | Housing/Shell | 4-40 | 5W5 | Nickel Plated Steel | 5 | 3 | DB B | 1 | |||
 EDAC Inc. | Copper Alloy | 85 °C | -25 °C | Black | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | 5 A 40 A | Shielded | Panel Mount Through Hole | Combo D-Sub | 30 Áin | 0.76 Ám | UL94 V-0 | Signal and Power | 2 | IP67 - Dust Tight Waterproof | Gold | Receptacle Female Sockets | Housing/Shell (M3) | 1 | 5W1 DE E | Nickel Plated Steel | 5 | ||||||
 EDAC Inc. | Copper Alloy | 85 °C | -25 °C | Black | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | Shielded | Panel Mount Through Hole | Combo D-Sub | 30 Áin | 0.76 Ám | Solder | UL94 V-0 | Signal and Power | 2 | IP67 - Dust Tight Waterproof | Gold | Receptacle Female Sockets | Housing/Shell (M3) | 1 | 5W1 DE E | Nickel Plated Steel | 5 | 20A 5A | |||||
 EDAC Inc. | Copper Alloy | 85 °C | -25 °C | Black | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | 40 A | Shielded | Panel Mount | Combo D-Sub | 15 µin | 0.38 µm | Solder | UL94 V-0 | Power | IP67 - Dust Tight Waterproof | Gold | Receptacle Female Sockets | Housing/Shell (M3) | 5W5 | Nickel Plated Steel | 5 | 3 | DB B | 1 | ||||
 EDAC Inc. | Copper Alloy | 85 °C | -25 °C | Black | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | 30 A | Shielded | Panel Mount | Combo D-Sub | 15 µin | 0.38 µm | Solder | UL94 V-0 | Power | IP67 - Dust Tight Waterproof | Gold | Receptacle Female Sockets | Housing/Shell (M3) | 5W5 | Nickel Plated Steel | 5 | 3 | DB B | 1 | ||||
 EDAC Inc. | Copper Alloy | 85 °C | -25 °C | Black | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | Shielded | Panel Mount Through Hole | Combo D-Sub | 15 µin | 0.38 µm | Solder | UL94 V-0 | Signal and Power | 2 | IP67 - Dust Tight Waterproof | Gold | Receptacle Female Sockets | Housing/Shell | 4-40 | 1 | 5W1 DE E | Nickel Plated Steel | 5 | 10A 5A | ||||
 EDAC Inc. | Copper Alloy | 85 °C | -25 °C | Black | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | 5 A 40 A | Shielded | Panel Mount Through Hole | Combo D-Sub | 30 Áin | 0.76 Ám | UL94 V-0 | Signal and Power | 2 | IP67 - Dust Tight Waterproof | Gold | Receptacle Female Sockets | Housing/Shell | 4-40 | 1 | 5W1 DE E | Nickel Plated Steel | 5 | |||||
 EDAC Inc. | Copper Alloy | 85 °C | -25 °C | Black | Polybutylene Terephthalate (PBT) Glass Filled | 125 VDC | 20 A | Shielded | Panel Mount | Combo D-Sub | 30 Áin | 0.76 Ám | Solder | UL94 V-0 | Power | IP67 - Dust Tight Waterproof | Gold | Receptacle Female Sockets | Housing/Shell | 4-40 | 5W5 | Nickel Plated Steel | 5 | 3 | DB B | 1 |
