1172L Series

Catalog

AE C&C LSZH /500 FT /EACH

Part	Cable Type	Jacket Color	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Material	Conductor Insulation	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Usage	Number of Conductors	Wire Gauge	Length	Length	Conductor Material	Voltage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length [x]	Length [x]
ALPHA WIRE 1172L SL002	Multi-Conductor	Slate	30 AWG	7	Low Smoke Zero Halogen (LSZH)	Low Smoke Zero Halogen (LSZH)	0.635 mm	0.025 in	Communication Control	2	22 AWG	152.4 m	500 ft	Copper Tinned	300 VDC	0.161 "	4.09 mm
ALPHA WIRE 1172L SL005	Multi-Conductor	Slate	30 AWG	7	Low Smoke Zero Halogen (LSZH)	Low Smoke Zero Halogen (LSZH)	0.635 mm	0.025 in	Communication Control	2	22 AWG			Copper Tinned	300 VDC	0.161 "	4.09 mm	100 ft	30.5 m
