851-002 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN PLUG FMALE 2P GOLD SLDR CUP
| Part | Insert Material | Applications | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Material | Contact Finish - Mating | Mounting Feature | Ingress Protection | Connector Type | Shielding | Color | Primary Material | Shell Size - Insert | Fastening Type | Shell Finish | Voltage Rating | Shell Material | Mounting Type | Number of Positions | Material Flammability Rating | Orientation | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Industrial Medical | 0.25 µm | 10 µin | Brass | Gold | Bulkhead - Rear Side Nut | IP67 - Dust Tight Waterproof | Plug Female Sockets | Shielded | Silver | Metal | M5-2 | Threaded | Nickel | 60 VDC | Brass | Panel Mount | 2 | UL94 V-0 | Keyed | 85 °C | -40 C | |
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Industrial Medical | Brass | Gold | Bulkhead - Rear Side Nut | IP67 - Dust Tight Waterproof | Plug Female Sockets | Shielded | Silver | Metal | M5-2 | Threaded | Nickel | 60 VDC | Brass | Panel Mount | 2 | UL94 V-0 | Keyed | 85 °C | -40 C | Flash | ||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Industrial Medical | Brass | Gold | Bulkhead - Front Side Nut | IP67 - Dust Tight Waterproof | Receptacle Male Pins | Shielded | Silver | Metal | M5-2 | Threaded | Nickel | 60 VDC | Brass | Panel Mount | 2 | UL94 V-0 | Keyed | 85 °C | -40 C | Flash |
