OA200AN Series
Manufacturer: ORION FANS
Beta
⌘K
AXIAL FAN, AC, OA200AN-METAL SERIES, BALL BEARING, CIRCULAR, 485CFM, 68DB, 230V, 105W, 3300RPM
| Part | Material - Blade | Lifetime @ Temp. | Material - Frame | RPM | Fan Type | Termination | Air Flow | Air Flow | Voltage - Rated | Width [x] | Size / Dimension [x] | Size / Dimension | Size / Dimension [z] | Approval Agency | Noise | Power (Watts) | Features | Weight [custom] | Weight [custom] | Bearing Type | Ingress Protection | Static Pressure | Static Pressure | Voltage Range [Max] | Voltage Range [Min] | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ORION FANS | Metal | 50000 Hrs | Aluminum | 3300 RPM | Tubeaxial | 2 | 13.58 m³/min | 485 CFM | 230 VAC | 70 mm | 220 mm | Rectangular/Rounded | 200 mm | cURus TUV | 68 dB | 105 W | Capacitor Thermal Overload Protector (TOP) | 1.8 kg | 4 lbs | Ball | IP56 - Dust Protected Water Resistant | 0.93 in H2O | 231.7 Pa | |||
 ORION FANS | Metal | 50000 Hrs | Aluminum | 3300 RPM | Tubeaxial | 13.58 m³/min | 485 CFM | 115 VAC | 70 mm | 220 mm | Rectangular/Rounded | 200 mm | cURus TUV | 68 dB | 105 W | Capacitor Thermal Overload Protector (TOP) | 1.8 kg | 4 lbs | Ball | IP56 - Dust Protected Water Resistant | 0.93 in H2O | 231.7 Pa | 120 VAC | 100 VAC | 2 Wire Leads | |
 ORION FANS | Metal | 50000 Hrs | Aluminum | 3300 RPM | Tubeaxial | 13.58 m³/min | 485 CFM | 230 VAC | 70 mm | 220 mm | Rectangular/Rounded | 200 mm | cURus TUV | 68 dB | 105 W | Capacitor Thermal Overload Protector (TOP) | 1.8 kg | 4 lbs | Ball | IP56 - Dust Protected Water Resistant | 0.93 in H2O | 231.7 Pa | 2 Wire Leads | |||
 ORION FANS | Metal | 50000 Hrs | Aluminum | 3300 RPM | Tubeaxial | 2 | 13.58 m³/min | 485 CFM | 115 VAC | 70 mm | 220 mm | Rectangular/Rounded | 200 mm | cURus TUV | 68 dB | 105 W | Capacitor Thermal Overload Protector (TOP) | 1.8 kg | 4 lbs | Ball | IP56 - Dust Protected Water Resistant | 0.93 in H2O | 231.7 Pa | 120 VAC | 100 VAC |
