C3CPS-5 Series

Catalog

IDC CABLE - CKC50S/AE50G/CPC50S

Part	Connector Type	Number of Positions	Pitch - Cable	Pitch - Cable	Contact Finish Thickness	Contact Finish Thickness	Cable Termination	Length [x]	Length [x]	Features	Shielding	Contact Finish	Usage	Pitch - Connector	Pitch - Connector	Length	Length	Length	Color
CW Industries C3CPS-5018G	Socket to PCB	50	0.05 in	1.27 mm	2.54 µm	100 µin	IDC	457.2 mm	1.5 ft	Polarizing Key	Unshielded	Tin	Board In	0.1 in	2.54 mm
CW Industries C3CPS-5006G	Socket to PCB	50	0.05 in	1.27 mm	2.54 µm	100 µin	IDC			Polarizing Key	Unshielded	Tin	Board In	0.1 in	2.54 mm	152.4 mm	0.5 '	6 "
CW Industries C3CPS-5036M	Socket to PCB	50	0.05 in	1.27 mm	2.54 µm	100 µin	IDC			Polarizing Key	Unshielded	Tin	Board In	0.1 in	2.54 mm	91.44 cm	3 ft		Multiple Ribbon
CW Industries C3CPS-5036G	Socket to PCB	50	0.05 in	1.27 mm	2.54 µm	100 µin	IDC			Polarizing Key	Unshielded	Tin	Board In	0.1 in	2.54 mm	91.44 cm	3 ft
CW Industries C3CPS-5018M	Socket to PCB	50	0.05 in	1.27 mm	2.54 µm	100 µin	IDC	457.2 mm	1.5 ft	Polarizing Key	Unshielded	Tin	Board In	0.1 in	2.54 mm				Multiple Ribbon
CW Industries C3CPS-5006M	Socket to PCB	50	0.05 in	1.27 mm	2.54 µm	100 µin	IDC			Polarizing Key	Unshielded	Tin	Board In	0.1 in	2.54 mm	152.4 mm	0.5 '	6 "	Multiple Ribbon
