357-031 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SGL FML 31POS 0.156
...
| Part | Contact Finish | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Mounting Type | Number of Positions/Bay/Row [custom] | Material - Insulation | Read Out | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Number of Positions | Gender | Termination Rows | Number of Rows | Pitch [x] | Pitch [x] | Card Type | Contact Type | Color | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Features | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Tin | 3.96 mm | Flush Mount Top Opening Unthreaded | 0.156 in | Through Hole Right Angle | 31 | Polyester Thermoplastic | Single | Copper Alloy | -40 °C | 105 ░C | Solder | 31 | Female | 1 | 1 | 0.156 in | 3.96 mm | Non Specified - Single Edge | Semi Bellows | Black | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | |||
 EDAC Inc. | Tin | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | 31 | Polyester Thermoplastic | Dual | Copper Alloy | -40 °C | 105 ░C | Solder | 62 | Female | 1 | 2 | 0.156 in | 3.96 mm | Non Specified - Dual Edge | Semi Bellows | Black | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Card Guides | ||||
 EDAC Inc. | Gold | Flush Mount M3 Threaded Insert Top Opening | Through Hole | 31 | Polyester Thermoplastic | Dual | Copper Alloy | -40 °C | 105 ░C | Solder | 62 | Female | 1 | 2 | 0.156 in | 3.96 mm | Non Specified - Dual Edge | Semi Bellows | Black | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | |||
 EDAC Inc. | Gold | Flush Mount M3 Threaded Insert Top Opening | Through Hole Right Angle | 31 | Polyester Thermoplastic | Single | Copper Alloy | -40 °C | 105 ░C | Solder | 31 | Female | 1 | 1 | 0.156 in | 3.96 mm | Non Specified - Single Edge | Semi Bellows | Black | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | |||
 EDAC Inc. | Tin | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | 31 | Polyester Thermoplastic | Single | Copper Alloy | -40 °C | 105 ░C | Wire Wrap | 31 | Female | 1 | 1 | 0.156 in | 3.96 mm | Non Specified - Single Edge | Semi Bellows | Black | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Card Guides | ||||
 EDAC Inc. | Tin | Flush Mount M3 Threaded Insert Top Opening | Through Hole | 31 | Polyester Thermoplastic | Single | Copper Alloy | -40 °C | 105 ░C | Solder | 31 | Female | 1 | 1 | 0.156 in | 3.96 mm | Non Specified - Single Edge | Semi Bellows | Black | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | |||||
 EDAC Inc. | Gold | 3.25 mm | Flush Mount Top Opening Unthreaded | 0.128 " | Through Hole Right Angle | 31 | Polyester Thermoplastic | Single | Copper Alloy | -40 °C | 105 ░C | Solder | 31 | Female | 1 | 1 | 0.156 in | 3.96 mm | Non Specified - Single Edge | Semi Bellows | Black | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | |
 EDAC Inc. | Gold | Through Hole | 31 | Polyester Thermoplastic | Single | Copper Alloy | -40 °C | 105 ░C | Wire Wrap | 31 | Female | 1 | 1 | 0.156 in | 3.96 mm | Non Specified - Single Edge | Semi Bellows | Black | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | ||||
 EDAC Inc. | Tin | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | 31 | Polyester Thermoplastic | Dual | Copper Alloy | -40 °C | 105 ░C | Wire Wrap | 62 | Female | 1 | 2 | 0.156 in | 3.96 mm | Non Specified - Dual Edge | Semi Bellows | Black | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Card Guides | ||||
 EDAC Inc. | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | 31 | Polyester Thermoplastic | Single | Copper Alloy | -40 °C | 105 ░C | Wire Wrap | 31 | Female | 1 | 1 | 0.156 in | 3.96 mm | Non Specified - Single Edge | Semi Bellows | Black | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Card Guides | 10 Áin | 0.25 Ám |
