AC/DC Power Modules 20W/12V MED AC/DC ENCAPSULATED
AC/DC Power Modules 20W/12V MED AC/DC ENCAPSULATED
| Part | Approval Agency | Current - Output (Max) [Max] | Package / Case | Mounting Type | Type | Power (Watts) | Features | Voltage - Input [Min] | Voltage - Input [Max] | Standard Number | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Output 1 | Number of Outputs | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Applications | Efficiency | Voltage - Isolation | Current - Output 1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TT Electronics/BI | CB CE cURus | 833 mA | 4-DIP Module | Through Hole | Enclosed | 20 W | Universal Input | 90 VAC 120 VDC | 264 VAC 370 VDC | 60601-1 60950-1 | 80 ¯C | -40 °C | 24 V | 1 | 23.5 mm | 0.93 " | 1.08 in | 27.5 mm | 52.5 mm | 2.07 in | ITE (Commercial) Medical | |||
 TT Electronics/BI | CB CE cURus | Chassis Mount | Enclosed | 20 W | DC Input Capable Universal Input | 90 VAC 120 VDC | 264 VAC 370 VDC | 60601-1 60950-1 | 80 ¯C | -40 °C | 12 V | 1 | 96 mm | 3.78 in | 1.14 " | 29 mm | 53.8 mm | 2.12 in | ITE (Commercial) Medical | 83 % | 4000 V | 1.66 A | ||
TT Electronics/BI | CB CE cURus | Chassis Mount | Enclosed | 20 W | DC Input Capable Universal Input | 90 VAC 120 VDC | 264 VAC 370 VDC | 60601-1 60950-1 | 80 ¯C | -40 °C | 24 V | 1 | 96 mm | 3.78 in | 1.14 " | 29 mm | 53.8 mm | 2.12 in | ITE (Commercial) Medical | 4000 V | 833 mA | |||
 TT Electronics/BI | CB CE cURus | 1.667 A | 4-DIP Module | Through Hole | Enclosed | 20 W | Universal Input | 90 VAC 120 VDC | 264 VAC 370 VDC | 60601-1 60950-1 | 80 ¯C | -40 °C | 12 V | 1 | 23.5 mm | 0.93 " | 1.08 in | 27.5 mm | 52.5 mm | 2.07 in | ITE (Commercial) Medical | 83 % |
