RAVHD1 Series
Manufacturer: SWITCHCRAFT/CONXALL
Beta
⌘K
HDMI CONNECTOR, TYPE A, RF/EMI PROTECTION, 19 CONTACTS, RECEPTACLE, PCB MOUNT
| Part | Shell/Shielding Material | Insulation Color | Contact Finish | Shielding | Connector Type | Gender | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Current Rating (Amps) | Mounting Feature | Voltage - Rated | Number of Ports | Number of Contacts | Mating Cycles | Mounting Type | Specifications | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SWITCHCRAFT/CONXALL | Brass | Black | Gold | Shielded | HDMI | Receptacle | Solder | 85 °C | -25 °C | 0.5 A | Flag Vertical | 40 V | 1 | 19 | 5000 | Right Angle Through Hole | HDMI 2.0 | |
 SWITCHCRAFT/CONXALL | Brass | Black | Gold | Shielded | HDMI | Receptacle | Solder | 85 °C | -25 °C | 0.5 A | Flag Vertical | 40 V | 1 | 19 | 5000 | Right Angle Through Hole | HDMI 2.0 | Board Guide |
