3355 Series

Catalog

CBL RIBN 40COND 0.05 GRY FEET

Part	First Conductor Mark	Spool Size [x]	Spool Size [x]	Conductor Material	Insulation Resistance	Ribbon Thickness	Ribbon Thickness	Length	Length	Operating Temperature [Min]	Operating Temperature [Max]	Ribbon Width [custom]	Ribbon Width [custom]	Jacket (Insulation) Material	Cable Type	Length	Jacket Color	Pitch	Pitch	Conductor Strand [custom]	Conductor Strand [custom]	Shielding	Wire Gauge	Number of Conductors	Features	Voltage	Length [x]	Length [x]	Number of Conductors [custom]
3M Electronic Specialty 3355/40 100	Blue	30.48 m	100 ft	Copper Tinned	10 GOhm	0.89 mm	0.035 in	100 '	30.48 m	-40 C	105 ░C	2 in	50.8 mm	Thermoplastic Elastomer (TPE)	Flat Cable	Enter Number of Feet in Order Quantity	Gray	0.05 in	1.27 mm	36 AWG	7 Strands	Unshielded	28 AWG	40	Zippable	300 VDC
3M Electronic Specialty 3355/16	Blue			Copper Tinned	10 GOhm	0.89 mm	0.035 in	100 '	30.48 m	-40 C	105 ░C	0.8 in	20.32 mm	Thermoplastic Elastomer (TPE)	Flat Cable	Enter Number of Feet in Order Quantity	Gray	0.05 in	1.27 mm	36 AWG	7 Strands	Unshielded	28 AWG	16	Zippable	300 VDC
3M Electronic Specialty 3355/14 100	Blue			Copper Tinned	10 GOhm	0.89 mm	0.035 in	1 ft 10 ft 25 ft 100 '	3.05 m 7.62 m 30.48 m 304.8 mm	-40 C	105 ░C	0.7 in	17.78 mm	Thermoplastic Elastomer (TPE)	Flat Cable		Gray	0.05 in	1.27 mm	36 AWG	7 Strands	Unshielded	28 AWG	14	Zippable	300 VDC	50 ft	15.24 m
3M Electronic Specialty 3355/09 100	Blue	30.48 m	100 ft	Copper Tinned	10 GOhm	0.89 mm	0.035 in	1 ft 10 ft 25 ft 100 '	3.05 m 7.62 m 30.48 m 304.8 mm	-40 C	105 ░C	0.45 in	11.43 mm	Thermoplastic Elastomer (TPE)	Flat Cable	Enter Number of Feet in Order Quantity	Gray	0.05 in	1.27 mm	36 AWG	7 Strands	Unshielded	28 AWG	9	Zippable	300 VDC	50 ft	15.24 m
3M Electronic Specialty 3355/10 300	Blue			Copper Tinned	10 GOhm	0.89 mm	0.035 in	3600 in	91440 mm	-40 C	105 ░C	0.5 in	12.7 mm	Thermoplastic Elastomer (TPE)	Flat Cable		Gray	0.05 in	1.27 mm	36 AWG	7 Strands	Unshielded	28 AWG		Zippable	300 VDC			10
3M Electronic Specialty 3355/10 100	Blue	30.48 m	100 ft	Copper Tinned	10 GOhm	0.89 mm	0.035 in	100 '	30.48 m	-40 C	105 ░C	0.5 in	12.7 mm	Thermoplastic Elastomer (TPE)	Flat Cable	Enter Number of Feet in Order Quantity	Gray	0.05 in	1.27 mm	36 AWG	7 Strands	Unshielded	28 AWG		Zippable	300 VDC			10
3M Electronic Specialty 3355/18	Blue			Copper Tinned	10 GOhm	0.89 mm	0.035 in	100 '	30.48 m	-40 C	105 ░C	0.9 in	22.86 mm	Thermoplastic Elastomer (TPE)	Flat Cable		Gray	0.05 in	1.27 mm	36 AWG	7 Strands	Unshielded	28 AWG	18	Zippable	300 VDC
3M Electronic Specialty 3355/20 100	Blue			Copper Tinned	10 GOhm	0.89 mm	0.035 in	100 '	30.48 m	-40 C	105 ░C	1 in	25.4 mm	Thermoplastic Elastomer (TPE)	Flat Cable	Enter Number of Feet in Order Quantity	Gray	0.05 in	1.27 mm	36 AWG	7 Strands	Unshielded	28 AWG	20	Zippable	300 VDC
3M Electronic Specialty 3355/24 100	Blue			Copper Tinned	10 GOhm	0.89 mm	0.035 in	1 ft 10 ft 25 ft 100 '	3.05 m 7.62 m 30.48 m 304.8 mm	-40 C	105 ░C	1.2 in	30.48 mm	Thermoplastic Elastomer (TPE)	Flat Cable		Gray	0.05 in	1.27 mm	36 AWG	7 Strands	Unshielded	28 AWG	24	Zippable	300 VDC	50 ft	15.24 m
3M Electronic Specialty 3355/60 100SF	Blue			Copper Tinned	10 GOhm	0.89 mm	0.035 in	100 '	30.48 m	-40 C	105 ░C	3 in	76.2 mm	Thermoplastic Elastomer (TPE)	Flat Cable		Gray	0.05 in	1.27 mm	36 AWG	7 Strands	Unshielded	28 AWG	60	Splice Free Zippable	300 VDC
