ECC-A3 Series

Manufacturer: Panasonic Electronic Components

Catalog

CAP CER 12PF 3KV SL/GP RADIAL

Part	Features	Lead Spacing	Lead Spacing	Tolerance	Temperature Coefficient	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Package / Case	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Voltage - Rated	Voltage - Rated	Applications	Lead Style	Size / Dimension [diameter]	Size / Dimension [diameter]	Capacitance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
Panasonic Electronic Components ECC-A3F120JGE	High Voltage	0.295 in	7.5 mm	5 %	SL/GP	105 ░C	-25 °C	Through Hole	Disc Radial	11 mm	0.433 in	3000 V	3 kV	General Purpose	Formed Leads	0.276 in	7 mm	12 pF
Panasonic Electronic Components ECC-A3D270JGE	High Voltage	0.295 in	7.5 mm	5 %	SL/GP	105 ░C	-25 °C	Through Hole	Disc Radial	11 mm	0.433 in	2000 V	2 kV	General Purpose	Formed Leads	0.276 in	7 mm	27 pF
Panasonic Electronic Components ECC-A3J470JGE	High Voltage	0.295 in	7.5 mm	5 %	SL/GP	105 ░C	-25 °C	Through Hole	Disc Radial	13 mm	0.512 "	6000 V	6 kV	General Purpose	Formed Leads	0.354 in	9 mm	47 pF
Panasonic Electronic Components ECC-A3D151JGE	High Voltage	0.295 in	7.5 mm	5 %	SL/GP	105 ░C	-25 °C	Through Hole	Disc Radial	13 mm	0.512 "	2000 V	2 kV	General Purpose	Formed Leads	0.354 in	9 mm	150 pF
Panasonic Electronic Components ECC-A3A470JGE	High Voltage	0.197 "	5 mm	5 %	SL/GP	105 ░C	-25 °C	Through Hole	Disc Radial			1000 V	1 kV	General Purpose	Formed Leads	0.236 in	6 mm	47 pF	10 mm	0.394 in
Panasonic Electronic Components ECC-A3D470JGE	High Voltage	0.295 in	7.5 mm	5 %	SL/GP	105 ░C	-25 °C	Through Hole	Disc Radial	11 mm	0.433 in	2000 V	2 kV	General Purpose	Formed Leads	0.276 in	7 mm	47 pF
Panasonic Electronic Components ECC-A3F151JGE	High Voltage	0.295 in	7.5 mm	5 %	SL/GP	105 ░C	-25 °C	Through Hole	Disc Radial	15 mm	0.591 "	3000 V	3 kV	General Purpose	Formed Leads	0.433 "	11 mm	150 pF
Panasonic Electronic Components ECC-A3A820JGE	High Voltage	0.197 "	5 mm	5 %	SL/GP	105 ░C	-25 °C	Through Hole	Disc Radial			1000 V	1 kV	General Purpose	Formed Leads	0.236 in	6 mm	82 pF	10 mm	0.394 in
Panasonic Electronic Components ECC-A3A101JGE	High Voltage	0.197 "	5 mm	5 %	SL/GP	105 ░C	-25 °C	Through Hole	Disc Radial	11 mm	0.433 in	1000 V	1 kV	General Purpose	Formed Leads	0.276 in	7 mm	100 pF
Panasonic Electronic Components ECC-A3F101JGE	High Voltage	0.295 in	7.5 mm	5 %	SL/GP	105 ░C	-25 °C	Through Hole	Disc Radial			3000 V	3 kV	General Purpose	Straight	0.394 in	10 mm	100 pF	14 mm	0.551 in
