HLMP-6720 Series

Catalog

LED YELLOW DIFF YOKE LEAD SMD

Part	Size / Dimension [y]	Size / Dimension [x]	Lens Size [diameter]	Lens Transparency	Lens Style	Color	Supplier Device Package	Wavelength - Dominant [custom]	Millicandela Rating	Configuration	Package / Case	Mounting Type	Current - Test	Viewing Angle [custom]	Voltage - Forward (Vf) (Typ)	Height (Max) [Max]	Wavelength - Peak	Lens Color
Broadcom Limited HLMP-6720-F0021	2.21 mm	2.08 mm	1.78 mm	Diffused	Round with Domed Top	Yellow	Yoke Lead	585 nm	2 mcd	Standard	2-SMD Yoke Bend	Surface Mount	10 mA	90 °	5 V	2.92 mm	583 nm
Broadcom Limited HLMP-6720-F0011	2.21 mm	2.08 mm	1.78 mm	Diffused	Round with Domed Top	Yellow	Gull Wing	585 nm	2 mcd	Standard	2-SMD Gull Wing	Surface Mount	10 mA	90 °	5 V	2.92 mm	583 nm
Broadcom Limited HLMP-6720	2.21 mm	2.08 mm	1.78 mm	Diffused	Round with Domed Top	Yellow	Axial	585 nm	2 mcd	Standard	Axial Flat Leads	Axial Through Hole	10 mA	90 °	5 V	2.92 mm	583 nm	Yellow
Broadcom Limited HLMP-6720-F0031	2.21 mm	2.08 mm	1.78 mm	Diffused	Round with Domed Top	Yellow	Z-Bend	585 nm	2 mcd	Standard	2-SMD Z-Bend	Surface Mount	10 mA	90 °	5 V	2.92 mm	583 nm
