PAAM60 Series

Encapsulated Power Supply 9V 60 Watt, Chassis Mount

Manufacturer: TT Electronics/BI

Catalog

Encapsulated Power Supply 9V 60 Watt, Chassis Mount

Catalog

Encapsulated Power Supply 9V 60 Watt, Chassis Mount

Part	Voltage - Output 1	Number of Outputs	Features	Type	Power (Watts)	Voltage - Input [Min]	Voltage - Input [Max]	Approval Agency	Current - Output (Max)	Efficiency	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Mounting Type	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Applications	Standard Number	Current - Output (Max) [Max]	Voltage - Isolation	Current - Output 1	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]
TT Electronics/BI PAAM60-12	12 V	1	Universal Input	Enclosed	60 W	90 VAC 120 VDC	264 VAC 370 VDC	CB CE cURus	5 A	88 %	80 ¯C	-40 °C	7-DIP Module 4 Leads	Through Hole	1.06 in	27 mm	89 mm	3.5 "	2.5 "	63.5 mm	ITE (Commercial) Medical	60601-1 60950-1
TT Electronics/BI PAAM60-10	5.1 V	1	Universal Input	Enclosed	51 W	90 VAC 120 VDC	264 VAC 370 VDC	CB CE cURus		86 %	80 ¯C	-40 °C	7-DIP Module 4 Leads	Through Hole	1.06 in	27 mm	89 mm	3.5 "	2.5 "	63.5 mm	ITE (Commercial) Medical	60601-1 60950-1	10 A
TT Electronics/BI PAAM60-14C	24 V	1	DC Input Capable Universal Input	Enclosed	60 W	90 VAC 120 VDC	264 VAC 370 VDC	CB CE cURus		87 %	80 ¯C	-40 °C		Chassis Mount		1.3 in	4.44 in			2.54 in	ITE (Commercial) Medical	60601-1 60950-1		4000 V	2.5 A	112.8 mm	64.5 mm	33 mm
TT Electronics/BI PAAM60-14	24 V	1	Universal Input	Enclosed	60 W	90 VAC 120 VDC	264 VAC 370 VDC	CB CE cURus		87 %	80 ¯C	-40 °C	7-DIP Module 4 Leads	Through Hole	1.06 in	27 mm	89 mm	3.5 "	2.5 "	63.5 mm	ITE (Commercial) Medical	60601-1 60950-1	2.5 A
TT Electronics/BI PAAM60-10C	5.1 V	1	DC Input Capable Universal Input	Enclosed	51 W	90 VAC 120 VDC	264 VAC 370 VDC	CB CE cURus		86 %	80 ¯C	-40 °C		Chassis Mount		1.3 in	4.44 in			2.54 in	ITE (Commercial) Medical	60601-1 60950-1		4000 V	10 A	112.8 mm	64.5 mm	33 mm
TT Electronics/BI PAAM60-13	15 V	1	Universal Input	Enclosed	60 W	90 VAC 120 VDC	264 VAC 370 VDC	CB CE cURus		86 %	80 ¯C	-40 °C	7-DIP Module 4 Leads	Through Hole	1.06 in	27 mm	89 mm	3.5 "	2.5 "	63.5 mm	ITE (Commercial) Medical	60601-1 60950-1	4 A
TT Electronics/BI PAAM60-13C	15 V	1	DC Input Capable Universal Input	Enclosed	60 W	90 VAC 120 VDC	264 VAC 370 VDC	CB CE cURus		86 %	80 ¯C	-40 °C		Chassis Mount		1.3 in	4.44 in			2.54 in	ITE (Commercial) Medical	60601-1 60950-1		4000 V	4 A	112.8 mm	64.5 mm	33 mm
TT Electronics/BI PAAM60-12C	12 V	1	DC Input Capable Universal Input	Enclosed	60 W	90 VAC 120 VDC	264 VAC 370 VDC	CB CE cURus		88 %	80 ¯C	-40 °C		Chassis Mount		1.3 in	4.44 in			2.54 in	ITE (Commercial) Medical	60601-1 60950-1		4000 V	5 A	112.8 mm	64.5 mm	33 mm
