VEU10 Series
Manufacturer: XP Power
Beta
⌘K
AC/DC WALL MOUNT ADAPTER 5V 10W
| Part | Output Connector | Approval Agency | Input Connector | Efficiency | Region Utilized | Voltage - Input [Max] | Voltage - Input [Min] | Current - Output (Max) [Max] | Standard Number | No Load Power Consumption | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Output | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Input Type | Power (Watts) | Form |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 XP Power | USB A Receptacle | CB CCC TUV UL | BS 1363 | CoC Tier 2 Level VI | United Kingdom | 264 VAC | 90 VAC | 2.1 A | 62368-1 | 75 mW | ITE (Commercial) | 0 °C | 60 °C | 5 V | 2 in | 1.92 " | 1.68 " | 42.7 mm | 48.8 mm | 50.8 mm | Fixed Blade Multi-Blade | 10 W | Wall Mount |
 XP Power | USB A Receptacle | CB CCC TUV UL | NEMA 1-15P | CoC Tier 2 Level VI | North America | 264 VAC | 90 VAC | 2.1 A | 62368-1 | 75 mW | ITE (Commercial) | 0 °C | 60 °C | 5 V | 2 in | 1.45 in | 0.86 " | 21.8 mm | 36.8 mm | 50.8 mm | Fixed Blade Multi-Blade | 10 W | Wall Mount |
 XP Power | USB A Receptacle | CB CCC TUV UL | CEE 7/16 | CoC Tier 2 Level VI | Europe | 264 VAC | 90 VAC | 2.1 A | 62368-1 | 75 mW | ITE (Commercial) | 0 °C | 60 °C | 5 V | 2.2 in | 1.45 in | 0.86 " | 21.8 mm | 36.8 mm | 55.9 mm | Fixed Blade Multi-Blade | 10 W | Wall Mount |
