STTC Series

Manufacturer: Metcal

Catalog

CARTRIDGE, CONICAL, 0.4MM (0.016IN), LL

Part	Tip Chip Size	Diameter [diameter]	Diameter [diameter]	Length [x]	Length [x]	For Use With/Related Products	Tip Type	Tip Shape	Temperature Range	Temperature Range	Width [x]	Width [x]	Length	Length	Width	Width
Metcal STTC-122LL	Chip	0.4 mm	0.016 in	8.4 mm	0.331 in	MX-500 MX-5200	Soldering	Conical	390 °C	734 °F
Metcal STTC-065						MX-500 MX-5000 MX-5200 MX-H1-AV MX-H7-SF MX-RM3E MX-RM6E	Soldering	Chisel	357 °C	675 °F	5 mm	0.197 in	0.449 in	11.4 mm
Metcal STTC-125	Chip						Soldering	Chisel				0.039 in	0.358 in	9.1 mm	1 mm
Metcal STTC-144LL	Chip	0.5 mm	0.02 in			MX-500 MX-5200	Soldering	Conical	390 °C	734 °F			0.571 "	14.5 mm
Metcal STTC-840V1	Chip	0.4 mm	0.016 in			MX-500 MX-5200	Soldering	Conical	450 °C	842 °F			0.63 in	16 mm
Metcal STTC-865						MX-500 MX-5000 MX-5200 MX-H1-AV MX-H7-SF MX-RM3E MX-RM6E	Rework	Chisel	510 °C	950 °F			0.45 in	11.43 mm	0.2 in	0.2 in
Metcal STTC-836PV1	Chip					MX-500 MX-5200	Soldering	Chisel	450 °C	842 °F	2.5 mm	0.098 in	0.39 "	9.91 mm
Metcal STTC-838-PK						MX-500 MX-5000 MX-5200 MX-H1-AV MX-H7-SF MX-RM3E MX-RM6E	Soldering	Chisel	510 °C	950 °F			0.39 "	9.91 mm	1.5 mm	0.059 in
Metcal STTC-101P						MX-500 MX-5000 MX-5200 MX-H1-AV MX-H7-SF MX-RM3E MX-RM6E	Soldering	Conical	413 °C	775 °F		0.039 in	0.531 in	13.5 mm	1 mm
Metcal STTC-099						MX-500 MX-5000 MX-5200 MX-H1-AV MX-H7-SF MX-RM3E MX-RM6E	Soldering	Chisel Bent 30°	357 °C	675 °F			0.469 "	11.91 mm	1.5 mm	0.059 in
