2532 Series
Manufacturer: Oupiin
Beta
⌘K
CONN FFC FPC TOP 9POS 1.25MM R/A
| Part | Housing Color | Mounting Type | Number of Positions | FFC, FCB Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Cable End Type | Height Above Board | Height Above Board | Contact Finish | Termination | Connector/Contact Type | Material Flammability Rating | Pitch | Pitch | Contact Material | Flat Flex Type | Housing Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Oupiin | Black | Right Angle Through Hole | 9 | 0.3 mm | -55 C | 105 ░C | Straight | 5 mm | 0.197 in | Tin | Kinked Pin | Contacts Top | UL94 V-0 | 0.049 in | 1.25 mm | Phosphor Bronze | FFC FPC | Polybutylene Terephthalate (PBT) Glass Filled |
