180 CPS Series

Catalog

ALUMINUM ORGANIC POLYMER CAPACITORS 820UF 16V 20%

Part	Operating Temperature (Min)	Operating Temperature (Max)	Size / Dimension Diameter	Applications	Tolerance	Lifetime	Surface Mount Land Length	Surface Mount Land Width	Type	Mounting Type	Capacitance	Ripple Current	Impedance	Height - Seated (Max)	Voltage - Rated	Package / Case
Vishay Dale MAL218097511E3	-55 °C	105 °C	0.394 in	General Purpose	20 %	2000 Hrs	0.409 in	0.409 in	Polymer	Surface Mount	820 µF	5.4 A	12 mOhm	0.496 in	16 V	Can - SMD Radial
Vishay Dale MAL218097501E3	-55 °C	105 °C	0.197 in	General Purpose	20 %	2000 Hrs	0.209 in	0.209 in	Polymer	Surface Mount	39 µF	2.35 A	20 mOhm	0.224 in	16 V	Can - SMD Radial
Vishay Dale MAL218097401E3	-55 °C	105 °C	0.197 in	General Purpose	20 %	2000 Hrs	0.209 in	0.209 in	Polymer	Surface Mount	68 µF	2.54 A	23 mOhm	0.224 in	10 V	Can - SMD Radial
Vishay Dale MAL218097258E3	-55 °C	105 °C	0.394 in	General Purpose	20 %	2000 Hrs	0.409 in	0.409 in	Polymer	Surface Mount	1200 µF	4.45 A	13 mOhm	0.303 in	2.5 V	Can - SMD Radial
Vishay Dale MAL218097601E3	-55 °C	105 °C	0.248 in	General Purpose	20 %	2000 Hrs	0.26 in	0.26 in	Polymer	Surface Mount	56 µF	2.8 A	30 mOhm	0.232 in	25 VAC	Can - SMD Radial
