T40320 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CIRCULAR METRIC CONNECTORS M8 MLE PNL FRONT 3POS STR
| Part | Applications | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Connector Type | Voltage Rating | Primary Material | Ingress Protection | Shell Finish | Current Rating (Amps) | Mounting Feature | Shell Material | Fastening Type | Orientation | Mounting Type | Contact Finish - Mating | Color | Shell Size - Insert | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Automation Control Industrial Telecommunications | 0.076 µm | 3 µin | Plug Male Pins | 60 VDC | Metal | IP67 - Dust Tight Waterproof | Nickel | 3 A | Bulkhead - Rear Side Nut | Copper Alloy | Threaded | A | Panel Mount | Gold | Silver | M8-3 | 85 °C | -40 C | |
 TE Connectivity AMP Connectors | Automation Control Industrial Telecommunications | 0.076 µm | 3 µin | Plug Male Pins | 30 VDC | Metal | IP67 - Dust Tight Waterproof | Nickel | 3 A | Bulkhead - Rear Side Nut | Copper Alloy | Threaded | A | Panel Mount | Gold | Silver | M8-4 | 85 °C | -40 C | 4 |
