VMS-550 Series
Manufacturer: CUI Inc.
Beta
⌘K
AC/DC CONVERTER 24V 150W
| Part | Mounting Type | Efficiency | Applications | Voltage - Isolation | Power (Watts) | Power (Watts) | Features | Number of Outputs | Approval Agency | Standard Number | Type | Voltage - Output 1 | Current - Output 1 | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Voltage - Input [Max] | Voltage - Input [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | Chassis Mount | 91 % | Medical | 4.2 kV | 550 W | 150 W | Adjustable Output Standby Output Universal Input | 1 | CB Scheme EN FCC IEC TUV UL | 55011 Class B; 60601-1; 61000-3-2; 61000-3-3 | Open Frame | 24 V | 6.25 A | 76.2 mm | 127 mm | 1.5 in | 3 " | 5 " | 38.1 mm | 264 VAC | 90 VAC |
CUI Inc. | Chassis Mount | 91 % | Medical | 4.2 kV | 550 W | 150 W | Adjustable Output PFC Standby Output Universal Input | 1 | CB Scheme EN FCC IEC TUV UL | 55011 Class B; 60601-1; 61000-3-2; 61000-3-3 | Open Frame | 30 V | 5 A | 76.2 mm | 127 mm | 1.5 in | 3 " | 5 " | 38.1 mm | 264 VAC | 90 VAC |
 CUI Inc. | Chassis Mount | 90 % | Medical | 4.2 kV | 500 W | 120 W | Adjustable Output PFC Standby Output Universal Input | 1 | CB Scheme EN FCC IEC TUV UL | 55011 Class B; 60601-1; 61000-3-2; 61000-3-3 | Open Frame | 15 V | 8 A | 76.2 mm | 127 mm | 1.5 in | 3 " | 5 " | 38.1 mm | 264 VAC | 90 VAC |
CUI Inc. | Chassis Mount | 90 % | Medical | 4.2 kV | 500 W | 120 W | Adjustable Output Standby Output Universal Input | 1 | CB Scheme EN FCC IEC TUV UL | 55011 Class B; 60601-1; 61000-3-2; 61000-3-3 | Open Frame | 12 V | 10 A | 76.2 mm | 127 mm | 1.5 in | 3 " | 5 " | 38.1 mm | 264 VAC | 90 VAC |
CUI Inc. | Chassis Mount | 92 % | Medical | 4.2 kV | 550 W | 150 W | Adjustable Output Standby Output Universal Input | 1 | CB Scheme EN FCC IEC TUV UL | 55011 Class B; 60601-1; 61000-3-2; 61000-3-3 | Open Frame | 48 V | 3.13 A | 76.2 mm | 127 mm | 1.5 in | 3 " | 5 " | 38.1 mm | 264 VAC | 90 VAC |
CUI Inc. | Chassis Mount | 92 % | Medical | 4.2 kV | 550 W | 150 W | Adjustable Output PFC Standby Output Universal Input | 1 | CB Scheme EN FCC IEC TUV UL | 55011 Class B; 60601-1; 61000-3-2; 61000-3-3 | Open Frame | 2.59 A | 76.2 mm | 127 mm | 1.5 in | 3 " | 5 " | 38.1 mm | 264 VAC | 90 VAC |
