5120UL Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 2COND 14AWG BLACK
| Part | Usage | Wire Gauge | Voltage | Jacket (Insulation) Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Length | Length | Cable Type | Number of Conductors | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Conductor Strand | Jacket Color | Conductor Insulation | Features | Conductor Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Alarm Safety | 14.5 AWG | 300 VDC | Poly-Vinyl Chloride (PVC) Riser | 0.205 in | 5.21 mm | 304.8 m | 1000 ft | Multi-Conductor | 2 | 0.017 " | 0.432 mm | Solid | Black | Polypropylene (PP) | Rip Cord | Copper Bare |
Belden Inc. | Alarm Safety | 14.5 AWG | 300 VDC | Poly-Vinyl Chloride (PVC) Riser | 0.205 in | 5.21 mm | 304.8 m | 1000 ft | Multi-Conductor | 2 | 0.017 " | 0.432 mm | Solid | Violet | Polypropylene (PP) | Rip Cord | Copper Bare |
Belden Inc. | Alarm Safety | 14.5 AWG | 300 VDC | Poly-Vinyl Chloride (PVC) Riser | 0.205 in | 5.21 mm | 304.8 m | 1000 ft | Multi-Conductor | 2 | 0.017 " | 0.432 mm | Solid | Orange | Polypropylene (PP) | Rip Cord | Copper Bare |
 Belden Inc. | Alarm Safety | 14.5 AWG | 300 VDC | Poly-Vinyl Chloride (PVC) Riser | 0.205 in | 5.21 mm | 304.8 m | 1000 ft | Multi-Conductor | 2 | 0.017 " | 0.432 mm | Solid | Red | Polypropylene (PP) | Rip Cord | Copper Bare |
Belden Inc. | Alarm Safety | 14.5 AWG | 300 VDC | Poly-Vinyl Chloride (PVC) Riser | 0.205 in | 5.21 mm | 304.8 m | 1000 ft | Multi-Conductor | 2 | 0.017 " | 0.432 mm | Solid | Red | Polypropylene (PP) | Rip Cord | Copper Bare |
Belden Inc. | Alarm Safety | 14.5 AWG | 300 VDC | Poly-Vinyl Chloride (PVC) Riser | 0.205 in | 5.21 mm | 304.8 m | 1000 ft | Multi-Conductor | 2 | 0.017 " | 0.432 mm | Solid | Red | Polypropylene (PP) | Rip Cord | Copper Bare |
Belden Inc. | Alarm Safety | 14.5 AWG | 300 VDC | Poly-Vinyl Chloride (PVC) Riser | 0.205 in | 5.21 mm | 304.8 m | 1000 ft | Multi-Conductor | 2 | 0.017 " | 0.432 mm | Solid | Blue | Polypropylene (PP) | Rip Cord | Copper Bare |
Belden Inc. | Alarm Safety | 14.5 AWG | 300 VDC | Poly-Vinyl Chloride (PVC) Riser | 0.205 in | 5.21 mm | 304.8 m | 1000 ft | Multi-Conductor | 2 | 0.017 " | 0.432 mm | Solid | Yellow | Polypropylene (PP) | Rip Cord | Copper Bare |
