EC5SBW-C(D)MF Series
Manufacturer: Cincon Electronics Co. LTD
Beta
⌘K
ISOLATED DC/DC CONVERTERS - CHASSIS MOUNT 30W 24VIN +/12VOUT 1.25A CHASSIS
| Part | Number of Outputs | Voltage - Input (Min) [Min] | Mounting Type | Type | Applications | Voltage - Isolation | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Efficiency | Operating Temperature [Min] | Operating Temperature [Max] | Approval Agency | Current - Output (Max) | Standard Number | Power (Watts) | Voltage - Output 1 | Voltage - Output 2 | Voltage - Input (Max) [Max] | DC Voltage - Input (Max) [Max] | Size / Dimension [z] | Size / Dimension [y] | Input Type | DC Voltage - Input (Min) [Min] | Features | Current - Output (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cincon Electronics Co. LTD | 2 | 10 VDC | Chassis Mount | Open Frame | ITE (Commercial) | 1.5 kV | 1.2 " | 1.48 in | 37.6 mm | 30.5 mm | 84.1 mm | 3.31 " | 88.5 % | -40 °C | 85 °C | CE UKCA | 1.25 A | 62368-1 | 30 Watts | 12 V | -12 V | 36 V | |||||||
Cincon Electronics Co. LTD | 1 | ITE (Commercial) | 1.5 kV | 3.31 in 84.1 mm | -40 °C | 85 °C | CE UKCA | 62368-1 | 30 Watts | 15 V | 36 V | 1.21 " 30.7 mm | 1.48 " 37.6 mm | DC | 10 V | Adjustable Output Remote On/Off | 2 A |
