395-048 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 48POS 0.100
...
| Part | Material - Insulation | Termination Rows [custom] | Termination | Pitch | Pitch | Color | Contact Finish | Read Out | Contact Material | Card Type | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows [custom] | Features | Number of Positions/Bay/Row | Flange Feature | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Gender | Termination Rows | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Solder | 0.1 " | 2.54 mm | Black | Gold | Dual | Copper Alloy | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 48 | Cantilever | -40 C | 105 ░C | 2 | Card Extender Card Guides | 24 | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Female | ||||
 EDAC Inc. | Polyester Thermoplastic | Wire Wrap | 0.1 " | 2.54 mm | Black | Gold | Single | Copper Alloy | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 48 | Cantilever | -40 C | 105 ░C | 48 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | 1 | 0.156 " | 3.96 mm | 1 | ||||
 EDAC Inc. | Polyester Thermoplastic | Wire Wrap | 0.1 " | 2.54 mm | Black | Gold | Single | Copper Alloy | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 48 | Cantilever | -40 C | 105 ░C | 48 | Side Mount Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | 1 | 0.128 " | 3.25 mm | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Solder | 0.1 " | 2.54 mm | Black | Gold | Dual | Copper Alloy | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 48 | Cantilever | -40 C | 105 ░C | 2 | 24 | M3 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Female | |||||
 EDAC Inc. | Polyester Thermoplastic | Solder | 0.1 " | 2.54 mm | Black | Gold | Single | Copper Alloy | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 48 | Cantilever | -40 C | 105 ░C | 48 | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | 1 | 0.128 " | 3.25 mm | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | Wire Wrap | 0.1 " | 2.54 mm | Black | Gold | Single | Copper Alloy | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 48 | Cantilever | -40 C | 105 ░C | 48 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | 1 | 1 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Wire Wrap | 0.1 " | 2.54 mm | Black | Gold | Dual | Copper Alloy | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 48 | Cantilever | -40 C | 105 ░C | 2 | Card Guides | 24 | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Solder | 0.1 " | 2.54 mm | Black | Gold | Dual | Copper Alloy | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 48 | Cantilever | -40 C | 105 ░C | 2 | 24 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Solder | 0.1 " | 2.54 mm | Black | Gold | Dual | Copper Alloy | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 48 | Cantilever | -40 C | 105 ░C | 2 | 24 | Floating Bobbin Flush Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Female | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyester Thermoplastic | Solder | 0.1 " | 2.54 mm | Black | Gold | Single | Copper Alloy | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 48 | Cantilever | -40 C | 105 ░C | 48 | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Female | 1 | 1 |
