325-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 25POS 0.100
| Part | Material - Insulation | Termination Rows | Contact Finish | Gender | Mounting Type | Number of Positions | Flange Feature | Pitch | Pitch | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness | Card Thickness | Contact Finish Thickness | Contact Finish Thickness | Termination | Contact Type | Contact Material | Number of Rows | Color | Number of Positions/Bay/Row | Read Out | Card Type | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Female | Through Hole | 25 | Flush Mount M3 Threaded Insert Top Opening | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Cantilever | Copper Alloy | 1 | Green | 25 | Single | Non Specified - Single Edge | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Female | Through Hole | 25 | Flush Mount M3 Threaded Insert Top Opening | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Solder | Cantilever | Copper Alloy | 1 | Green | 25 | Single | Non Specified - Single Edge | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Female | Through Hole | 25 | Flush Mount M3 Threaded Insert Top Opening | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Wire Wrap | Cantilever | Copper Alloy | 1 | Green | 25 | Single | Non Specified - Single Edge | ||
EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Female | Through Hole | 25 | 4-40 Flush Mount Threaded Insert Top Opening | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Cantilever | Copper Alloy | 1 | Green | 25 | Single | Non Specified - Single Edge | ||
EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Female | Through Hole | 25 | 4-40 Flush Mount Threaded Insert Top Opening | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Wire Wrap | Cantilever | Copper Alloy | 1 | Green | 25 | Single | Non Specified - Single Edge | ||
EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Female | Through Hole | 25 | Flush Mount Top Opening Unthreaded | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Cantilever | Copper Alloy | 1 | Green | 25 | Single | Non Specified - Single Edge | 0.16 " | 4.06 mm |
