SRN5030HA Series
Manufacturer: Bourns Inc.
Beta
⌘K
POWER INDUCTORS - SMD IND,5X5X3MM,1.5UH+/-30%,6.4A,150C,SHD AEC-Q200
| Part | Inductance | Mounting Type | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Operating Temperature [Min] | Operating Temperature [Max] | Q @ Freq | Tolerance | Frequency - Self Resonant | Type | Current - Saturation (Isat) | Material - Core | Inductance Frequency - Test | DC Resistance (DCR) [Max] | Package / Case | Ratings | Shielding | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 1.5 µH | Surface Mount | 0.118 " | 3 mm | 0.197 in | 0.197 " | 5 mm | 5 mm | -55 C | 150 °C | 7.96 MHz 13 | 30 % | 67 MHz | Drum Core Wirewound | 6.4 A | Ferrite | 100 kHz | 26 mOhm | Nonstandard | AEC-Q200 | Shielded | 4.2 A |
